G3200 XH Cylinder Head Assembly

#PartDescriptionPriceReqNotesAvailability
1 273-9468 Thermal valve cover short $2.35 1 usually ships 7-19 days
2 273-9469 Valve screw $7.12 1 usually ships 7-19 days
3 273-9470 O-ring seal $2.49 1 usually ships 7-19 days
4 273-9471 O-ring seal $2.97 1 usually ships 7-19 days
5 273-9472 Thermo valve tin $14.25 1 usually ships 7-19 days
6 273-9473 Helical Spring $1.57 1 usually ships 7-19 days
7 273-9474 Unloader assembly $21.23 1 ships same day
8 273-9475 Nozzle $2.35 1 usually ships 7-19 days
9 273-9476 Chemistry set $52.03 1 usually ships 7-19 days
10 273-9444 Drain plug $13.53 3 usually ships 7-19 days
11 273-9442 Pressure check valve set $25.19 1 usually ships 7-19 days
12 273-9442 Pressure check valve set $25.19 1 usually ships 7-19 days
13 273-9441 Plate $1.50 1 usually ships 7-19 days
14 273-9478 Cylinder head $87.99 1 usually ships 7-19 days
15 999-9079 Screw M8 x 80mm hex head stainless steel $4.41 4 ships same day
16 273-9628 Quick connect $9.57 1 usually ships 7-19 days
