| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
272-4393
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
4 |
272-4394
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
6 |
272-4395
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
7 |
272-4396
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
8 |
272-4397
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
9 |
272-4398
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
14 |
272-4399
|
Hydraulic hose (OBSOLETE) |
2 |
|
|
15 |
272-4400
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
16 |
272-4401
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
29 |
272-4402
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
30 |
272-4403
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
31 |
272-4404
|
Hydraulic hose (OBSOLETE) |
1 |
|
|
40 |
272-4405
|
Hydraulic hose |
1 |
|
|
50 |
272-4406
|
Oil tank (OBSOLETE) |
1 |
|
|
51 |
272-4370
|
Hydraulic oil filter |
1 |
|
|
52 |
272-4370
|
Hydraulic oil filter |
1 |
|
|
53 |
272-4370
|
Hydraulic oil filter |
1 |
|
|
54 |
272-4407
|
Pump (OBSOLETE) |
1 |
|
|
55 |
272-4031
|
V1505T Kubota engine (OBSOLETE) |
1 |
|
|
56a |
272-4037
|
Left side motor wheel (OBSOLETE) |
1 |
|
|
56b |
272-4034
|
Motor wheel kit (OBSOLETE) |
1 |
(please verify model on motorwheel before placing order) |
|
57a |
272-4033
|
Right side motor wheel (OBSOLETE) |
1 |
|
|
57b |
272-4034
|
Motor wheel kit (OBSOLETE) |
1 |
(please verify model on motorwheel before placing order) |
|
61 |
272-4408
|
Hydraulic hand pump (OBSOLETE) |
1 |
|
|
64 |
272-4409
|
Hydraulic oil cooler (OBSOLETE) |
1 |
|
|
76 |
272-4410
|
Complete drive pedal assembly (OBSOLETE) |
1 |
|
|
77 |
272-4367
|
Filter assembly |
1 |
|
|
78 |
272-4373
|
Hydraulic oil filter |
1 |
|
|
81 |
272-4411
|
Filling plug |
1 |
|
|
