| # | Part | Description |
Req | Notes | Availability |
|---|
2 |
272-5476
|
Wheel |
1 |
|
|
5 |
272-5550
|
110V Solenoid valve |
1 |
|
|
12 |
172-3717
|
Flanged bearing |
2 |
|
|
14 |
181-0924
|
Solution filter assembly |
1 |
|
|
16 |
272-5477
|
Bracket |
1 |
|
|
17 |
272-5478
|
Support |
1 |
|
|
18 |
272-5479
|
Plate |
1 |
|
|
19 |
272-5480
|
Bracket |
1 |
|
|
23 |
270-0409
|
Gas spring |
1 |
|
|
24 |
272-5481
|
Rubber elbow holder |
2 |
|
|
26 |
181-0923
|
Solution screen and gasket kit |
1 |
|
|
27 |
272-5483
|
Hose 12 x 380mm |
1 |
|
|
28 |
272-7108
|
100mm hose |
1 |
|
|
29 |
272-5484
|
Hose 10 x 90mm |
1 |
|
|
30 |
272-2669
|
Hose clamp (OBSOLETE) |
3 |
|
|
34 |
272-5553
|
Solenoid cable valve (OBSOLETE) |
1 |
|
|
N/S |
272-7113
|
Connector |
1 |
|
|
N/S |
272-5552
|
Solenoid valve kit (OBSOLETE) |
1 |
(includes 5, 14, 22, 24, 27, 28, 29, 30) |
|
N/S |
272-5486
|
Solution system hardware kit |
1 |
|
|
