| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
999-1482
|
Nut 3/8-16 nylon lock stainless steel |
$1.06
|
2 |
(included in Kit 1) |
ships same day |
2 |
999-6692
|
Nut 1/2-20 hex nylon lock stainless steel |
$3.52
|
1 |
(included in Kit 1) |
usually ships 19-32 days |
3 |
999-9128
|
Washer 3/8 SAE flat stainless steel |
$2.11
|
4 |
(included in Kit 1) |
ships same day |
4 |
999-0296
|
Nut 5/16-24 nylon insert lock stainless steel |
$0.99
|
2 |
(included in Kit 1) |
ships same day |
5 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$0.99
|
2 |
(included in Kit 1) |
ships same day |
6 |
N/A
|
Not available |
Call for price
|
2 |
(Screw) (only available in Kit 1) |
usually ships 3-26 days |
7 |
N/A
|
Not available |
Call for price
|
1 |
(Washer) (only available in Kit 1 and Kit 2) |
usually ships 3-26 days |
8 |
N/A
|
Not available |
Call for price
|
2 |
(Washer) (only available in Kit 1) |
usually ships 3-26 days |
9 |
999-0802
|
Screw M8-1.25 x 16mm socket head |
$0.99
|
1 |
(included in Kit 1 and Kit 2) |
ships same day |
10 |
N/A
|
Not available |
Call for price
|
3 |
(Screw) (only available in Kit 1 and Kit 2) |
usually ships 3-26 days |
11 |
472-3868
|
CASTER WHEEL |
$38.56
|
2 |
|
ships same day |
12 |
372-1618
|
Squeegee mount kit |
$63.07
|
1 |
|
usually ships 12-18 days |
13 |
472-4849
|
BEARING-FLANGE |
$12.31
|
2 |
|
ships same day |
14 |
472-4857
|
ROD END-1/2 |
$19.98
|
1 |
|
usually ships 12-18 days |
15 |
372-3006
|
Bracket |
$96.93
|
1 |
|
usually ships 12-18 days |
16 |
472-4859
|
TURNBUCKLE ASSEMBLY-9.40 INCH |
$30.61
|
1 |
|
ships same day |
17 |
N/A
|
Not available |
Call for price
|
1 |
(squeegee lift lever) (only available in Kit 2 and Kit 3) |
usually ships 3-26 days |
18 |
N/A
|
Not available |
Call for price
|
1 |
(knob) (only available in Kit 2) |
usually ships 3-26 days |
19 |
572-4228
|
8 inch cable tie (black) |
$5.39
|
1 |
|
usually ships 12-18 days |
20a |
372-1278
|
Squeegee assembly |
$413.78
|
1 |
(28 inch and 34 inch disc) |
ships same day |
20b |
472-4915
|
SQUEEGEE ASSY-42-RED GUM |
$490.19
|
1 |
(32 inch cylindrical) |
usually ships 12-18 days |
21 |
372-1317
|
Squeegee lift cable assembly |
$31.10
|
1 |
|
ships same day |
22 |
272-2141
|
Extension spring |
$24.60
|
2 |
|
usually ships 12-18 days |
23 |
N/A
|
Not available |
Call for price
|
3 |
(bushing) (only available in Kit 2) |
usually ships 3-26 days |
24 |
372-2618
|
Squeegee seal |
$5.50
|
1 |
|
usually ships 12-18 days |
25 |
N/A
|
Not available |
Call for price
|
2 |
(washer) (only available in Kit 1) |
usually ships 3-26 days |
KIT1 |
372-1344
|
Squeegee hardware kit |
$24.60
|
1 |
(includes 1-10 and 25) |
usually ships 12-18 days |
KIT2 |
375-1345
|
Squeegee weldment bracket |
$198.99
|
1 |
(includes 7, 9-10, 17 and 23) |
ships same day |
KIT3 |
572-4031
|
Handle lever kit |
$121.68
|
1 |
(includes 17) |
usually ships 12-18 days |
