| # | Part | Description |
Req | Notes | Availability |
|---|
BT1 |
N/A
|
Not available |
|
(Battery) |
|
E1 |
272-6348
|
Speed control |
1 |
|
|
E2 |
272-2358
|
24V onboard battery charger |
1 |
|
|
E3a |
372-1633
|
Interface panel assembly |
1 |
|
|
E3b |
272-6350
|
Interface panel assembly (OBSOLETE) |
1 |
|
|
F1a |
172-8836
|
150amp fuse |
1 |
|
|
CB2 |
272-9374
|
10amp circuit breaker |
1 |
|
|
H1 |
172-8839
|
Backup alarm |
1 |
|
|
K1 |
272-8794
|
24V contactor |
1 |
|
|
K2 |
172-2163
|
24V solenoid 4 post (2 large 2 small) |
1 |
|
|
L1 |
272-9265
|
Solenoid valve |
1 |
|
|
LP1 |
272-9485
|
Warning beacon |
1 |
|
|
M2 |
272-3551
|
Lift actuator assembly |
1 |
|
|
M3 |
372-1261
|
Actuator |
1 |
|
|
M4 |
272-6547
|
Motor |
1 |
|
|
M5 |
272-6547
|
Motor |
1 |
|
|
M8 |
272-9271
|
Vacuum motor |
1 |
|
|
M9 |
272-9271
|
Vacuum motor |
1 |
|
|
M10 |
272-2175
|
Chemical pump |
1 |
|
|
SW1 |
272-9417
|
Seat switch |
1 |
|
|
SW2a |
272-2195
|
Key switch assembly |
1 |
|
|
SW2b |
272-2196
|
Keys (pkg of 2) |
1 |
(optional) |
|
SW3 |
172-9233
|
Emergency stop button |
1 |
|
|
