| # | Part | Description | Price | Req | Notes | Availability |
|---|
001a |
172-0083
|
3 inch guide wheel |
$13.40
|
1 |
|
ships same day |
001b |
991-3060
|
Bumper wheel |
$5.77
|
1 |
|
ships same day |
002 |
999-0114
|
Washer 1/2 SAE flat |
$0.99
|
6 |
|
ships same day |
003 |
999-0641
|
Screw 5/16-18 x 3/4 socket head stainless steel |
$1.19
|
2 |
|
ships same day |
004 |
999-0635
|
Nut 3/8-16 hex stainless steel |
$0.99
|
1 |
|
ships same day |
005 |
999-1931
|
Bolt 3/8-16 x 2 hex head full thread stainless steel |
$1.80
|
1 |
|
ships same day |
006 |
999-0324
|
Nut 3/8-16 nylon insert lock jam zinc plated |
$0.99
|
1 |
|
ships same day |
007 |
999-0266
|
Washer #8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
008 |
999-0916
|
Screw 8-32 x 1/2 pan head phillips stainless steel |
$0.99
|
4 |
|
ships same day |
009 |
999-9128
|
Washer 3/8 SAE flat stainless steel |
$2.11
|
1 |
|
ships same day |
010 |
172-2001
|
Hair cotter pin |
$10.56
|
3 |
|
usually ships 16-41 days |
011 |
997-2511
|
Cotter pin |
$0.99
|
2 |
|
ships same day |
012 |
172-0437
|
Square keyway |
$10.56
|
2 |
|
usually ships 16-41 days |
013 |
999-1036
|
Nut 8-32 hex NTM nylon insert jam lock stainless steel |
$0.99
|
4 |
|
ships same day |
014 |
172-8489
|
Screw 3/8-16 x 3/4 hex lock stainless steel |
$8.30
|
8 |
|
usually ships 1-5 days |
015 |
272-1835
|
Washer flat |
$11.99
|
2 |
|
usually ships 16-41 days |
016 |
272-2123
|
3/4 inch PVC hose |
$11.99
|
1 |
|
usually ships 16-41 days |
017 |
272-2124
|
Clevis pin |
$11.99
|
1 |
|
usually ships 16-41 days |
018 |
272-8172
|
Deck weldment |
$447.72
|
1 |
|
usually ships 16-41 days |
019 |
272-8173
|
Linkage pivot pin |
$23.95
|
1 |
|
usually ships 16-41 days |
020a |
272-8174
|
Left hand brush housing - includes skirts |
$156.64
|
1 |
|
ships same day |
020b |
272-8175
|
Left hand brush housing assembly |
$440.37
|
1 |
(includes 7, 8, 13, 20, and 31) |
ships same day |
021a |
272-8161
|
Right hand brush housing - includes skirts |
$156.64
|
1 |
|
usually ships 16-41 days |
021b |
272-8176
|
Right hand brush housing assembly |
$425.30
|
1 |
(includes 1, 4-6, 8, 9, 13, 15, 21, 30, and 33) |
ships same day |
022 |
272-8177
|
Cover decal |
$8.80
|
1 |
|
usually ships 1-5 days |
023 |
172-8490
|
#96 hose clamp SAE |
$26.92
|
1 |
|
usually ships 1-5 days |
024 |
172-2090
|
Motor shroud (OBSOELTE) |
$81.08
|
1 |
|
usually ships 16-41 days |
025 |
272-1384
|
Tee barb |
$11.99
|
1 |
|
usually ships 16-41 days |
026 |
272-1385
|
PVC hose |
$11.99
|
1 |
|
usually ships 16-41 days |
027a |
272-1344
|
36V brush gear motor assembly |
$1,789.15
|
2 |
(OEM) |
usually ships 1-5 days |
027b |
172-2056
|
Carbon brush (pkg of 4) |
$223.84
|
4 |
(for Imperial Electric motors) (OEM) |
usually ships 16-41 days |
027c |
172-2054
|
Brush spring |
$16.50
|
4 |
(for Imperial Electric motors) (OEM) |
usually ships 1-5 days |
027d |
472-7357
|
BRUSH BOARD ASSY |
$32.55
|
1 |
(for Nilfisk-Advance motors) (OEM) |
usually ships 16-41 days |
027e |
991-2122
|
36V .75HP brush motor assembly with gear box |
$1,099.40
|
1 |
(NON-OEM) (also need to order 027f) |
ships same day |
027f |
999-0130
|
Screw 5/16-18 x 3/4 socket head alloy plain finish |
$0.99
|
1 |
|
ships same day |
028 |
997-2102
|
Cable tie |
$1.24
|
4 |
|
ships same day |
029 |
170-0207
|
Male gimbal with collar |
$17.61
|
2 |
|
ships same day |
030 |
170-7029
|
Keeper |
$3.75
|
1 |
|
ships same day |
031 |
170-7019
|
Brush deck latch |
$41.15
|
1 |
|
ships same day |
033 |
170-7026
|
Latch tab |
$11.26
|
1 |
|
ships same day |
N/S |
472-6948
|
PAD HOLDER-17 GIMBAL |
$125.66
|
1 |
|
usually ships 16-41 days |
