| # | Part | Description | Price | Req | Notes | Availability |
|---|
0a |
472-7892
|
SKIRT ASSY-LEFT-28D |
$314.39
|
1 |
(28 inch) (includes 1-8) (If you have a machine built prior to January 20, 2014, order skirt assembly kit 0d. Original skirt assemblies are no longer available.) |
usually ships 16-41 days |
0b |
472-7893
|
SKIRT ASSY-LEFT-34D |
$337.39
|
1 |
(34 inch) (includes 1-8) (If you have a machine built prior to January 20, 2014, order skirt assembly kit 0e. Original skirt assemblies are no longer available.) |
usually ships 16-41 days |
0c |
472-7891
|
SKIRT ASSY-RIGHT-28-34D |
$321.78
|
1 |
(all models) (includes 1-4, 7, 9-11) (If you have a machine built prior to January 20, 2014, order skirt assembly kit 0d (28 inch) or 0e (34 inch). Original skirt assemblies are no longer available.) |
usually ships 16-41 days |
0d |
472-7889
|
SKIRT ASSY KIT-28 IN |
$643.69
|
1 |
(28 inch) (for models built prior to January 20, 2014) |
usually ships 16-41 days |
0e |
472-7890
|
SKIRT ASSY KIT-34 IN |
$658.46
|
1 |
(34 inch) (for models built prior to January 20, 2014) |
usually ships 16-41 days |
1 |
999-1948
|
Nut 1/4-20 wing lock |
$2.12
|
9 |
(qty of 10 in 0b) |
ships same day |
2 |
272-3627
|
Screw 1/4-20 x 3/4 carriage head stainless steel |
$12.31
|
1 |
|
usually ships 16-41 days |
3 |
272-3628
|
Screw 1/4-20 x 1 carriage head stainless steel |
$10.85
|
8 |
(qty of 9 in 0b) |
ships same day |
4 |
172-0548
|
Washer 17/64 x 47/64 flat stainless steel |
$10.85
|
1 |
|
usually ships 16-41 days |
5a |
472-7902
|
SKIRT BKT WELDT-LEFT-28D |
$73.04
|
1 |
(28 inch) (left hand side) |
usually ships 16-41 days |
5b |
472-7903
|
SKIRT BKT WELDT-LEFT-34D |
$77.99
|
1 |
(34 inch) (left hand side) |
usually ships 16-41 days |
6a |
472-7894
|
STRAP-FRONT-28-34D |
$10.85
|
1 |
(28 inch) (left hand side) |
usually ships 16-41 days |
6b |
472-7895
|
STRAP-FRONT-LEFT-34D |
$10.85
|
1 |
(34 inch) (left hand side) |
usually ships 16-41 days |
7a |
172-4687
|
Skirt blade kit gum rubber (tan) (set of 2) |
$85.98
|
1 |
(all disk deck blade kits include all side skirt blades) |
ships same day |
7b |
272-6387
|
Skirt blade kit polyurethane |
$276.82
|
1 |
(optional)(all disk deck blade kits include all side skirt blades) |
usually ships 16-41 days |
7c |
272-6388
|
Skirt blade kit gum rubber red (pkg of 4) |
$222.53
|
1 |
(optional)(all disk deck blade kits include all side skirt blades) |
ships same day |
8a |
472-4822
|
STRAP REAR 28D 34D |
$18.38
|
1 |
(28 inch) (left hand side) |
usually ships 16-41 days |
8b |
472-4823
|
STRAP REAR 34D LT |
$21.57
|
1 |
(34 inch) (left hand side) |
usually ships 16-41 days |
9 |
472-7901
|
SKIRT BKT WELDT-RIGHT-28-34D |
$84.15
|
1 |
(all models) (right hand side) |
usually ships 16-41 days |
10 |
472-4822
|
STRAP REAR 28D 34D |
$18.38
|
1 |
(all models) (right hand side) |
usually ships 16-41 days |
11 |
472-7894
|
STRAP-FRONT-28-34D |
$10.85
|
1 |
(all models) (right hand side) |
usually ships 16-41 days |
