| # | Part | Description |
Req | Notes | Availability |
|---|
CH1 |
172-3816
|
12V 20amp onboard battery charger |
1 |
|
|
CN1 |
N/A
|
Not available |
1 |
(Connector) |
|
CN2 |
172-3817
|
Charger connector (OBSOLETE) |
1 |
|
|
EB1 |
172-3790
|
Electronic card |
1 |
|
|
ES1 |
172-3794
|
Electromagnetic switch |
1 |
|
|
F1a |
272-5323
|
70amp circuit breaker (OBSOLETE) |
1 |
(after SN 1664872) (main) |
|
F1b |
272-5571
|
60 amp fuse |
1 |
(before SN 1664873) (main) |
|
F2 |
172-3648
|
15amp fuse |
1 |
(side brush) |
|
F3 |
272-9588
|
10amp fuse |
1 |
(signal) |
|
M1 |
172-3748
|
Electric motor (OBSOLETE) |
1 |
(traction) |
|
M2 |
172-3682
|
Brush gear motor (OBSOLETE) |
1 |
|
|
SW1 |
172-3785
|
Key switch with two keys |
1 |
|
|
SW2 |
172-3646
|
Safety switch |
1 |
|
|
