| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
N/A
|
Not available |
1 |
(Nut M8) |
|
2 |
272-5068
|
Handle adjustment ratchet |
2 |
|
|
3 |
272-5069
|
Handle adjustment ratchet |
2 |
|
|
4 |
172-3776
|
Clamp (OBSOLETE) |
1 |
|
|
5 |
172-3777
|
Adjuster (OBSOLETE) |
1 |
|
|
6 |
472-1423
|
CLEVIS M6X24 GALV. DIN71752 PK |
1 |
|
|
7 |
172-3779
|
Clip |
1 |
|
|
8 |
272-5322
|
Handle assembly (OBSOLETE) |
1 |
(includes 13b) |
|
9 |
N/A
|
Not available |
2 |
(Screw 8 x 130) |
|
10 |
272-0709
|
Handwheel |
2 |
|
|
11 |
272-9575
|
Locking clip (OBSOLETE) |
1 |
|
|
13a |
272-9576
|
Traction cable (OBSOLETE) |
4 |
(before SN 1664801) |
|
13b |
272-9577
|
Traction cable |
1 |
(after SN 1664800) |
|
N/S |
272-6551
|
Hardware kit |
1 |
(includes Screw M5 x 20, Screw M4 x 12 thread forming, Nut M8, Screw 8 x 130, Nut M6 self locking, Screw 4 x 8 thread forming and Washer 6 x 12 flat) |
|
