| # | Part | Description | Price | Req | Notes | Availability |
|---|
A1 |
272-7325
|
Function board service |
$628.06
|
1 |
|
usually ships 16-41 days |
A2 |
270-0215
|
24V I-Drive controller |
$628.06
|
1 |
|
usually ships 16-41 days |
A3 |
270-0345
|
Chemical module |
$390.80
|
1 |
|
usually ships 1-5 days |
F1a |
991-1630
|
35amp circuit breaker |
$29.52
|
1 |
(Disc and Boost) |
usually ships 16-41 days |
F1b |
991-1632
|
25amp circuit breaker |
$7.91
|
1 |
(Cylindrical) |
ships same day |
F2a |
991-1630
|
35amp circuit breaker |
$29.52
|
1 |
(Disc and Boost) |
usually ships 16-41 days |
F2b |
991-1632
|
25amp circuit breaker |
$7.91
|
1 |
(Cylindrical) |
ships same day |
F3 |
270-0217
|
30amp fuse |
$13.17
|
1 |
|
usually ships 16-41 days |
F4 |
N/A
|
Not available |
Call for price
|
1 |
(3amp fuse) |
usually ships 3-26 days |
F5 |
270-0218
|
60amp fuse |
$13.17
|
1 |
|
usually ships 1-5 days |
K1 |
270-0216
|
Relay |
$21.57
|
1 |
|
ships same day |
K2 |
172-2163
|
24V solenoid 4 post (2 large 2 small) |
$126.03
|
1 |
|
ships same day |
K7 |
270-0219
|
24V I-Drive relay |
$15.48
|
1 |
|
ships same day |
L1 |
170-1920
|
Solenoid valve |
$195.84
|
1 |
|
ships same day |
M1a |
170-1420
|
24V brush gear motor assembly |
$1,684.68
|
1 |
(26/28 Disc) |
usually ships 16-41 days |
M1b |
270-0299
|
Brush motor |
$1,179.74
|
1 |
(34 Disc) |
usually ships 1-5 days |
M1c |
270-0341
|
24V brush motor |
$1,761.07
|
1 |
(28 Cylindrical) |
usually ships 1-5 days |
M1d |
272-9948
|
24V brush motor |
$1,179.74
|
1 |
(Boost) |
ships same day |
M2a |
170-1420
|
24V brush gear motor assembly |
$1,684.68
|
1 |
(26/28 Disc) |
usually ships 16-41 days |
M2b |
270-0299
|
Brush motor |
$1,179.74
|
1 |
(34 Disc) |
usually ships 1-5 days |
M2c |
270-0341
|
24V brush motor |
$1,761.07
|
1 |
(28 Cylindrical) |
usually ships 1-5 days |
M4 |
N/A
|
Not available |
Call for price
|
1 |
(pump motor) |
usually ships 3-26 days |
M5a |
270-0259
|
24V actuator |
$697.08
|
1 |
(not used for Boost models) |
usually ships 16-41 days |
M5b |
272-3543
|
Actuator |
$995.83
|
1 |
(Boost models only) |
usually ships 16-41 days |
M6 |
270-0348
|
Chemical pump |
$651.08
|
1 |
|
usually ships 16-41 days |
M7 |
270-0275
|
Transaxle kit |
$2,373.51
|
1 |
|
usually ships 16-41 days |
M8 |
170-9080
|
24V 3 stage vacuum motor |
$462.00
|
1 |
|
usually ships 5-9 days |
R2 |
270-0199
|
Potentiometer harness assembly |
$44.58
|
1 |
|
usually ships 16-41 days |
S1 |
N/A
|
Not available |
Call for price
|
1 |
(power wand switch) |
usually ships 3-26 days |
S3 |
170-7081
|
Float switch (includes strain relief) |
$229.88
|
1 |
|
usually ships 16-41 days |
S4 |
170-7409
|
Push button reverse switch |
$90.43
|
1 |
|
usually ships 16-41 days |
