| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
N/A
|
Not available |
Call for price
|
1 |
(screw M5 x 50) (only available with KIT1) |
usually ships 3-26 days |
2 |
N/A
|
Not available |
Call for price
|
1 |
(M5 self locking nut) (only available with KIT1) |
usually ships 3-26 days |
4 |
N/A
|
Not available |
Call for price
|
2 |
(spacer) (only available with KIT1) |
usually ships 3-26 days |
5 |
572-3661
|
RING D 17 UNI7435 10 PCS SET |
$32.56
|
1 |
|
usually ships 13-18 days |
6 |
N/A
|
Not available |
Call for price
|
2 |
(washer) (only available with KIT1) |
usually ships 3-26 days |
7 |
172-3730
|
Square keyway |
$51.96
|
1 |
|
ships same day |
8 |
272-8313
|
Joint |
$149.81
|
1 |
|
usually ships 13-18 days |
9 |
272-9529
|
SCREW M5X10 CUP PT 10 PCS |
$40.16
|
1 |
|
usually ships 13-18 days |
10 |
270-8280
|
Flange bushing |
$22.58
|
2 |
|
usually ships 13-18 days |
11 |
572-3552
|
RING D.40 UNI7436 PKD |
$11.35
|
1 |
|
usually ships 13-18 days |
12 |
572-3684
|
TUBE STEERING KIT |
$93.17
|
1 |
|
usually ships 13-18 days |
13a |
572-3556
|
BEARING NEEDLE ROLLER 17/20 |
$58.98
|
1 |
(before SN 3510163104805) |
usually ships 13-18 days |
13b |
572-3683
|
HARDWARE STEERING SUPPORT KIT |
$66.03
|
1 |
|
usually ships 13-18 days |
13c |
372-3074
|
Bearing ball (OBSOLETE) |
Call for price
|
1 |
(after SN 3510163104804) |
usually ships 13-18 days |
14 |
572-3570
|
SHAFT STEERING UPPER PKD |
$22.58
|
1 |
|
usually ships 13-18 days |
15 |
572-3572
|
SUPPORT STEERING COLUMN PKD |
$353.25
|
1 |
|
usually ships 13-18 days |
16 |
572-3573
|
SHAFT STEERING LOWER PKD |
$51.96
|
1 |
|
usually ships 13-18 days |
17 |
572-3586
|
PINION Z25 PKD |
$70.59
|
1 |
|
usually ships 13-18 days |
KIT1 |
572-3626
|
HARDWARE STEERING TUBE KIT |
$14.41
|
1 |
(includes 1-4, 6) |
usually ships 13-18 days |
