| # | Part | Description | Price | Req | Notes | Availability |
|---|
2 |
N/A
|
Not available |
Call for price
|
1 |
(clamp) (only available with KIT2) |
usually ships 3-26 days |
3 |
N/A
|
Not available |
Call for price
|
5 |
(screw M5 x 12 hex head) (only available with KIT3) |
usually ships 3-26 days |
4 |
999-1801
|
Screw M6 X 12mm hex head flange |
$2.79
|
7 |
(included in KIT3) |
ships same day |
5 |
N/A
|
Not available |
Call for price
|
8 |
(screw M5 x 16 socket head) (only available with KIT3) |
usually ships 3-26 days |
6 |
N/A
|
Not available |
Call for price
|
2 |
(screw M6 x 30 socket head) (only available with KIT2) |
usually ships 3-26 days |
7 |
N/A
|
Not available |
Call for price
|
2 |
(flat washer) (only available with KIT2) |
usually ships 3-26 days |
8 |
N/A
|
Not available |
Call for price
|
1 |
(screw M6 x 12 rolling thread) (only available with KIT2) |
usually ships 3-26 days |
9 |
999-0609
|
Nut 1/4-20 hex stainless steel |
$0.99
|
2 |
(included in KIT1) |
ships same day |
10 |
999-1532
|
Screw 1/4-20 x 1/2 hex head stainless steel |
$0.99
|
1 |
(included in KIT1) |
ships same day |
11 |
N/A
|
Not available |
Call for price
|
1 |
(1/4-20 stud) (only available with KIT1) |
usually ships 3-26 days |
19 |
472-4961
|
MODULE-HIGH POWER |
$2,220.72
|
1 |
|
ships same day |
20 |
472-4974
|
SPEED CONTROL |
$3,522.13
|
1 |
|
usually ships 12-18 days |
22 |
472-5007
|
PLATE-CONTACTOR MOUNTING |
$48.18
|
1 |
|
usually ships 12-18 days |
23 |
472-5012
|
BUS BAR-CONTACTOR |
$12.31
|
1 |
|
usually ships 12-18 days |
24 |
472-5722
|
CONTACTOR 36V TYPE 4 |
$192.01
|
2 |
(includes KIT2 and KIT3) |
usually ships 12-18 days |
25 |
472-5026
|
HORN-36V |
$55.56
|
1 |
|
usually ships 12-18 days |
28 |
N/A
|
Not available |
Call for price
|
7 |
(M6 washer internal lock) (only available with KIT3) |
usually ships 3-26 days |
30 |
472-5206
|
HARNESS ASSEMBLY-BATTERY |
$452.27
|
1 |
|
usually ships 12-18 days |
31 |
N/A
|
Not available |
Call for price
|
1 |
(electrical mount) (only available with KIT1) |
usually ships 3-26 days |
32 |
N/A
|
Not available |
Call for price
|
5 |
(washer) (only available with KIT3) |
usually ships 3-26 days |
33 |
N/A
|
Not available |
Call for price
|
1 |
(screw M8 x 16 hex head) (only available with KIT2) |
usually ships 3-26 days |
34 |
N/A
|
Not available |
Call for price
|
5 |
(flat washer) (only available with KIT3) |
usually ships 3-26 days |
35 |
572-3833
|
Washer |
$6.22
|
4 |
|
usually ships 12-18 days |
36 |
N/A
|
Not available |
Call for price
|
1 |
(M6 nut nylon lock thin) (only available with KIT2) |
usually ships 3-26 days |
37 |
N/A
|
Not available |
Call for price
|
8 |
(flat washer) (only available with KIT2 and KIT3) |
usually ships 3-26 days |
39 |
N/A
|
Not available |
Call for price
|
5 |
(screw M6 x 20 pan head) (only available with KIT4) |
usually ships 3-26 days |
40 |
N/A
|
Not available |
Call for price
|
2 |
(M6 nut nylon lock thin) (only available with KIT4) |
usually ships 3-26 days |
41 |
N/A
|
Not available |
Call for price
|
2 |
(flat washer) (only available with KIT4) |
usually ships 3-26 days |
42 |
172-8828
|
Battery cable |
$48.18
|
5 |
|
ships same day |
43 |
272-6709
|
Terminal cover (black) |
$13.76
|
5 |
|
usually ships 1-5 days |
44 |
272-6707
|
Terminal cover (red) |
$12.31
|
5 |
|
usually ships 1-5 days |
N/S |
N/A
|
Not available |
Call for price
|
20 |
(clamp) (only available with KIT2) |
usually ships 3-26 days |
N/S |
472-4949
|
HARNESS-MAIN |
$3,904.67
|
1 |
|
usually ships 12-18 days |
N/S |
472-4932
|
150 amp fuse |
$19.98
|
1 |
|
usually ships 12-18 days |
N/S |
472-4952
|
HARNESS-TRACTION |
$367.77
|
1 |
|
usually ships 12-18 days |
N/S |
472-4953
|
CABLE-SPEED CONTROLLER-RED |
$31.10
|
1 |
|
usually ships 12-18 days |
N/S |
472-4954
|
CABLE-SPEED CONTROLLER-BLACK |
$18.38
|
1 |
|
usually ships 12-18 days |
N/S |
472-4955
|
CABLE-POWER MODULE-RED |
$41.54
|
1 |
|
usually ships 12-18 days |
N/S |
472-4956
|
CABLE-POWER MODULE-BLACK |
$23.01
|
1 |
|
usually ships 12-18 days |
N/S |
472-4957
|
HARNESS-MACHINE POWER |
$337.39
|
1 |
|
usually ships 12-18 days |
N/S |
472-5037
|
HARNESS-VACUUM FLOAT |
$118.65
|
1 |
|
usually ships 12-18 days |
N/S |
N/A
|
Not available |
Call for price
|
20 |
(cable tie mount) (only available with KIT2) |
usually ships 3-26 days |
N/S |
472-5175
|
HARNESS-SEAT SWITCH |
$31.10
|
1 |
|
usually ships 12-18 days |
N/S |
N/A
|
Not available |
Call for price
|
15 |
(cable tie) (only available with KIT2) |
usually ships 3-26 days |
KIT1 |
472-5229
|
ELECTRICAL MOUNT KIT |
$72.63
|
1 |
(includes 9-11, 31) |
usually ships 12-18 days |
KIT2 |
472-5218
|
HARDWARE KIT-ELECTRICAL |
$129.05
|
1 |
(includes 2, 6-8, 33, 36-37) |
usually ships 12-18 days |
KIT3 |
472-5191
|
HARDWARE KIT-CONTROLLERS |
$18.38
|
1 |
(includes 3-5, 28, 32, 34, 37) |
usually ships 12-18 days |
KIT4 |
472-5219
|
HARDWARE KIT-CONTACTOR ASSY |
$18.38
|
1 |
(includes 39-41) |
ships same day |
