| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
170-0316
|
Stator frame assembly (OBSOLETE) |
1 |
|
|
2 |
170-1414
|
Armature assembly (OBSOLETE) |
1 |
|
|
3 |
170-0320
|
Bottom bearing |
1 |
|
|
4 |
170-0321
|
Front end bearing |
1 |
|
|
5 |
N/A
|
Not available |
1 |
(commutator bracket assembly) |
|
6 |
170-0323
|
Commutator bracket (OBSOLETE) |
1 |
|
|
7 |
170-0324
|
Strain relief (OBSOLETE) |
2 |
|
|
8 |
999-0267
|
Screw 10-24 x 1/2 pan head phillips zinc |
2 |
|
|
9 |
170-0325
|
Brush board assembly (OBSOLETE) |
1 |
|
|
10 |
372-1685
|
Springs |
4 |
|
|
11 |
372-1648
|
Carbon brush assembly |
4 |
|
|
12 |
170-0328
|
Positive lead assembly (OBSOLETE) |
1 |
|
|
13 |
170-0329
|
Negative lead assembly (OBSOLETE) |
1 |
|
|
14 |
N/A
|
Not available |
1 |
(helical washer) |
|
15 |
164-1157
|
Bolt 1/4-20 x 7 3/4 thru |
2 |
|
|
16 |
170-1421
|
Shaft key |
1 |
|
|
17 |
991-5115
|
Gear box assembly |
1 |
|
|
