| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
372-1289
|
Air guide |
1 |
|
|
2 |
372-1296
|
Clamping plate |
1 |
|
|
3 |
372-1297
|
Strap |
1 |
|
|
4 |
372-1298
|
Distribution strip |
1 |
|
|
5 |
372-1299
|
Contact spring |
1 |
|
|
6 |
372-1300
|
Sealing kit |
1 |
|
|
7 |
272-7394
|
Motor kit |
1 |
|
|
8 |
372-1301
|
Screw |
1 |
|
|
9 |
372-1302
|
Screw |
1 |
|
|
10 |
372-1290
|
Sound insulation outlet |
1 |
|
|
11 |
372-1291
|
Screw |
3 |
|
|
12 |
N/A
|
Not available |
1 |
(Magnet mouting plate) (Only available in 372-1292) |
|
13 |
372-1292
|
110V solenoid valve |
1 |
(includes 11-12) |
|
14 |
372-1293
|
Bracket |
1 |
|
|
15 |
372-1294
|
Motor |
1 |
|
|
16 |
N/A
|
Not available |
1 |
(Cable) |
|
17 |
372-1295
|
Hose |
2 |
|
|
