| # | Part | Description | Price | Req | Notes | Availability |
|---|
BE |
372-3057
|
Beacon flashing |
$392.79
|
|
(beacon) |
usually ships 13-18 days |
BRK |
270-8301
|
Electric brake |
$721.96
|
|
(electromagnetic brake) |
usually ships 13-18 days |
BZ1 |
170-9221
|
Buzzer |
$82.28
|
|
(buzzer) |
usually ships 1-5 days |
C1 |
272-8374
|
120amp connector (red) |
$93.17
|
|
(battery connector) |
usually ships 13-18 days |
C4 |
991-9284
|
50amp charger plug SB50 with pins (red) |
$6.47
|
|
(brush deck connector) |
usually ships 1-5 days |
CH |
270-8393
|
24V onboard battery charger |
$798.50
|
|
(onboard charger) |
usually ships 13-18 days |
EB1 |
270-8383
|
Electronic traction card kit |
$1,539.52
|
|
(main electronic board) |
usually ships 13-18 days |
EB2 |
572-3363
|
CARD ELECTRONIC FUNCTIONS KIT |
$312.82
|
|
(control panel electronic board) |
ships same day |
EB3 |
270-8282
|
Control panel decal |
$281.00
|
|
(control panel electronic board decal) |
usually ships 13-18 days |
ES1 |
272-6327
|
24V electromagnetic switch |
$109.53
|
|
(brush motor switch) |
usually ships 5-7 days |
EV1 |
272-8536
|
24V solution solenoid valve |
$216.63
|
|
(electrovalve) |
ships same day |
F1 |
181-0964
|
50amp fuse |
$14.41
|
|
(brush deck fuse) |
usually ships 13-18 days |
F2 |
270-8388
|
100amp fuse |
$22.58
|
|
(main board fuse) |
usually ships 13-18 days |
F3 |
572-3491
|
FUSE BLADE 3A PKD |
$19.25
|
|
(low power circuit fuse) |
usually ships 13-18 days |
F4 |
172-3648
|
15amp fuse |
$12.89
|
|
(actuator fuse) |
usually ships 13-18 days |
K1 |
172-3785
|
Key switch with two keys |
$64.90
|
|
(key switch) |
ships same day |
M1.1 |
572-3695
|
REDUCTION GEARMOTOR 400W 24V K |
$1,683.87
|
|
(disc brush motors) |
usually ships 13-18 days |
M1.2 |
272-9948
|
24V brush motor |
$1,235.19
|
|
(boost brush motor) |
usually ships 13-18 days |
M2 |
991-1230
|
24V 3 stage vacuum motor tangential with snout |
$214.98
|
|
(vacuum motor) |
usually ships 18-24 days |
M3 |
572-3398
|
MOTOR ELECTRIC 300W 24V PKD |
$1,843.84
|
|
(drive motor) |
usually ships 13-18 days |
M4 |
172-4771
|
Chemical mix pump |
$457.31
|
|
(detergent pump) |
usually ships 13-18 days |
M5 |
270-8337
|
24V actuator motor |
$585.32
|
|
(disc brush deck actuator motor) |
ships same day |
M6 |
270-8323
|
Squeegee actuator |
$721.96
|
|
(squeegee actuator motor) |
usually ships 13-18 days |
PR1 |
270-8387
|
Pressure sensor kit |
$750.00
|
|
(water pressure gage) |
usually ships 13-18 days |
RV1 |
270-8272
|
Speed control pedal (OBSOLETE) |
$449.02
|
|
(drive pedal potentiometer) |
usually ships 1-5 days |
SW1 |
170-9209
|
Microswitch (OBSOLETE) |
$84.49
|
|
(microswitch seat) |
usually ships 13-18 days |
