| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
270-8290
|
Drive wheel kit |
$52.67
|
2 |
(pin) |
usually ships 17-28 days |
2 |
270-8290
|
Drive wheel kit |
$52.67
|
1 |
(clamp) |
usually ships 17-28 days |
3 |
270-8290
|
Drive wheel kit |
$52.67
|
4 |
(screw) |
usually ships 17-28 days |
4 |
270-8290
|
Drive wheel kit |
$52.67
|
3 |
(screw) |
usually ships 17-28 days |
5 |
270-8290
|
Drive wheel kit |
$52.67
|
4 |
(screw) |
usually ships 17-28 days |
6 |
270-8290
|
Drive wheel kit |
$52.67
|
4 |
(screw) |
usually ships 17-28 days |
7 |
270-8290
|
Drive wheel kit |
$52.67
|
3 |
(washer) |
usually ships 17-28 days |
8 |
270-8290
|
Drive wheel kit |
$52.67
|
3 |
(black clamp) |
usually ships 17-28 days |
9 |
270-8290
|
Drive wheel kit |
$52.67
|
1 |
(ring nut) |
usually ships 17-28 days |
10 |
270-8290
|
Drive wheel kit |
$52.67
|
1 |
(washer) |
usually ships 17-28 days |
11 |
272-3537
|
Ball bearing support |
$70.47
|
1 |
(ball bearing support) |
usually ships 17-28 days |
12 |
272-3535
|
Ball bearing |
$35.60
|
1 |
(bearing roller) |
usually ships 17-28 days |
13 |
270-8290
|
Drive wheel kit |
$52.67
|
1 |
(screw) |
usually ships 17-28 days |
14 |
270-8290
|
Drive wheel kit |
$52.67
|
1 |
(flat tie holder) |
usually ships 17-28 days |
15 |
270-8291
|
Crown steering spacer |
$29.23
|
1 |
(crown steering spacer) |
usually ships 1-5 days |
16 |
270-8292
|
Main gear |
$47.03
|
1 |
(main gear) |
usually ships 17-28 days |
17 |
270-8293
|
Wheel motor kit |
$3,904.67
|
1 |
(wheel motor kit) |
usually ships 1-5 days |
18 |
270-8294
|
Steering bracket |
$268.38
|
1 |
(steering bracket) |
usually ships 17-28 days |
19 |
270-8295
|
Steering crown |
$63.07
|
1 |
(steering crown) |
usually ships 1-5 days |
20 |
270-8296
|
Drive wheel protection |
$10.85
|
1 |
(drive wheel protection) |
usually ships 1-5 days |
21 |
270-8297
|
Drive wheel |
$375.16
|
1 |
(drive wheel) |
usually ships 17-28 days |
22 |
270-8298
|
Wheel motor harness |
$136.44
|
1 |
(wheel motor harness) |
usually ships 17-28 days |
23 |
272-3534
|
Ball bearing |
$36.32
|
1 |
(ball bearing) |
usually ships 17-28 days |
24 |
572-3398
|
MOTOR ELECTRIC 300W 24V PKD |
$1,761.07
|
1 |
(electric motor) |
usually ships 17-28 days |
25 |
270-8300
|
Carbon brush kit |
$116.47
|
1 |
(carbon brush kit) |
usually ships 1-5 days |
26 |
270-8290
|
Drive wheel kit |
$52.67
|
6 |
(screw) |
usually ships 17-28 days |
27 |
270-8290
|
Drive wheel kit |
$52.67
|
6 |
(washer) |
usually ships 17-28 days |
30 |
270-8301
|
Electric brake |
$689.56
|
1 |
(electric brake) |
usually ships 1-5 days |
31 |
270-8302
|
Oil seal |
$60.06
|
1 |
(oil seal) |
usually ships 1-5 days |
N/S |
270-8290
|
Drive wheel kit |
$52.67
|
1 |
(drive wheel kit, includes 1-10, 13, 14, 26, 27) |
usually ships 17-28 days |
