| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-0110
|
Screw 10-16 x 1/2 pan head phillips self-drilling |
3 |
|
|
2 |
999-0851
|
Screw 10-32 x 1/2 round head slotted nylon |
4 |
|
|
3 |
170-1885
|
Switch lever housing |
2 |
|
|
4 |
270-0632
|
Control handle |
1 |
|
|
5 |
170-2034
|
Nut 8-32 |
2 |
|
|
6 |
272-8476
|
Low voltage battery meter |
1 |
|
|
7 |
999-0311
|
Washer #10 external star lock zinc plated |
2 |
|
|
8 |
999-0460
|
Nut 10-32 hex |
2 |
|
|
9 |
270-0633
|
Control panel |
1 |
|
|
10 |
N/A
|
Not available |
1 |
|
|
11 |
999-0462
|
Screw 8-32 x 1/2 pan head slotted zinc plated |
2 |
|
|
12a |
170-0052
|
Hour meter |
1 |
(OEM) |
|
12b |
991-7137
|
Hour meter |
1 |
(NON-OEM) |
|
13 |
999-0414
|
Screw 10-32 x 3/4 pan head slotted zinc plated |
1 |
|
|
14 |
272-8524
|
Key switch spacer |
1 |
|
|
15 |
170-9026
|
Key switch |
1 |
|
|
N/S |
170-0080
|
Wire tie |
1 |
|
|
