| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
206-0627
|
Knob (OBSOLETE) |
1 |
|
|
2 |
206-0573
|
Washer special (OBSOLETE) |
1 |
|
|
3 |
206-5317
|
Clamp |
4 |
|
|
4 |
189-6201
|
Compression spring |
1 |
(Spring) |
|
5 |
206-5322
|
Rod (OBSOLETE) |
1 |
|
|
6 |
206-0997
|
Bellows (OBSOLETE) |
1 |
|
|
7 |
N/A
|
Not available |
1 |
(Valve lever) |
|
8 |
206-0616
|
Fitting (OBSOLETE) |
2 |
|
|
9 |
189-7634
|
3/8 double female ball valve |
1 |
|
|
10 |
206-0998
|
Pipe (OBSOLETE) |
1 |
|
|
11a |
189-7576
|
Solenoid valve |
1 |
|
|
11b |
189-7627
|
Solenoid valve body |
1 |
|
|
12a |
206-1001
|
Pipe (OBSOLETE) |
1 |
|
|
12b |
206-1002
|
Pipe (OBSOLETE) |
1 |
|
|
12c |
250-1661
|
Hose |
1 |
|
|
13 |
189-6325
|
Wire tie |
2 |
|
|
14 |
206-1003
|
Cap (OBSOLETE) |
1 |
|
|
15 |
206-5259
|
O-ring (OBSOLETE) |
1 |
|
|
50 |
999-0740
|
Nut M5-.8 hex stainless steel |
1 |
|
|
51 |
206-5328
|
Nut (OBSOLETE) |
1 |
|
|
52 |
189-8726
|
Washer M6 flat PVC black |
1 |
|
|
53 |
206-5266
|
Screw (OBSOLETE) |
1 |
|
|
54 |
250-1662
|
Split pin |
1 |
|
|
55 |
999-0521
|
Screw M4-.7 x 12mm pan head phillips zinc |
2 |
|
|
56 |
206-0995
|
Lock nut (OBSOLETE) |
2 |
|
|
