Solution Tank Assembly

#PartDescription ReqNotesAvailability
01a 250-1429 Bottom plate 1 (before SN 01004119)
01b 250-1430 Bottom plate 1 (after SN 01004120)
02 250-1431 Seat 1
03 189-3205 Safety switch 1
04 250-1433 Light 1
05 189-8545 Strobe light 1
08 250-1434 Gasket 1
09 250-1435 Support 1
10 250-1436 Prop 1
11 250-1437 Support 1
12 189-6201 Compression spring 1
13 206-0573 Washer special (OBSOLETE) 1
14 206-0627 Knob (OBSOLETE) 1
15 250-1438 Male coupling 1
16 189-5186 Solution solenoid valve 1
17 250-1440 Hose 2
18 250-1441 Hose 1
19 189-9215 Valve lever 1
20 206-0620 Clamp (OBSOLETE) 1
21 250-1443 Connector 1
22 N/A Not available 1 (faucet)
23 250-1444 Nipple 1
24 206-0997 Bellows (OBSOLETE) 1
25 206-0969 Connector (OBSOLETE) 1
26 250-1269 Clamp 1
27 250-1465 Hose 1
28 250-1466 Rod 1
29 250-1445 Pump assembly 1
30 250-1446 Door 1 (before SN 01004119)
31 250-1447 Hinge 2
33 250-1449 Handle 1 (before SN 01004119)
34 189-7543 Solution filter and housing assembly 1
35 189-7562 Micro switch 1
36 189-9218 Solution filter 1
37 189-8726 Washer M6 flat PVC black 2
38 250-1451 Coupler 1
39 250-1452 Solution tank 1
41 189-6379 Cap 1
42 189-6292 Gasket 1
43 189-6380 O-ring 1 (after SN 02001972)
44 250-1453 Decal 2
45a 250-1454 Decal 1
45b 250-1455 Decal 1
46 250-1456 Decal 1
47 250-1202 Connector 1
50 250-1457 Screw M6 x 25mm 2
51 189-9102 Washer external serrated lock zinc 1
52 206-0578 Washer (OBSOLETE) 6
53 206-0507 Screw 4
54 999-1312 Screw M6-1 x 20mm hex head stainless steel 2
55 250-1459 Screw M6 x 16mm 2
56 999-0740 Nut M5-.8 hex stainless steel 1
57 999-1261 Washer M6 flat stainless steel 4
58 999-0740 Nut M5-.8 hex stainless steel 1
60 250-1219 Washer 14
61 999-0471 Nut M8-1.25 nylon insert lock zinc plated 10
62 189-6198 Flat washer 10
63 206-0995 Lock nut (OBSOLETE) 1
64 250-1461 Screw M4 x 16mm 1
65 250-1462 Screw M3 x 35mm 2
66 250-1463 Nut M3 6
67 189-6278 Screw M4.2-.7 x 16mm pan head self tapping zinc plated 1
69 999-1261 Washer M6 flat stainless steel 4
70 206-0609 Screw (OBSOLETE) 2
71 250-1464 Screw 2
72 250-1439 Coil 1
73 189-7627 Solenoid valve body 1
