| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
246-0140
|
Rear spindle |
Call for price
|
1 |
|
usually ships 1-5 days |
1b |
246-0094
|
Nut 3/8-16 Stover lock |
Call for price
|
2 |
|
usually ships 1-5 days |
1c |
246-0118
|
Nut 3/4-10 finish jam |
Call for price
|
1 |
|
usually ships 1-5 days |
1d |
999-0630
|
Washer 3/4 SAE flat |
$0.99
|
1 |
|
ships same day |
2 |
246-0019
|
Clip set |
$38.20
|
1 |
|
usually ships 16-28 days |
3a |
246-0004
|
Rear belt tensioner pulley |
$4.24
|
1 |
(includes 3b-3e) |
usually ships 1-5 days |
3b |
246-0141
|
6 inch pulley hub |
Call for price
|
1 |
|
usually ships 1-5 days |
3c |
246-0142
|
1/2 inch bronze spacer |
Call for price
|
1 |
|
usually ships 1-5 days |
3d |
246-0116
|
Bearing |
Call for price
|
1 |
|
usually ships 1-5 days |
3e |
246-0115
|
Internal retaining ring |
Call for price
|
1 |
|
usually ships 1-5 days |
4 |
246-0143
|
24 inch flexi-disc |
Call for price
|
1 |
|
usually ships 1-5 days |
5 |
999-6743
|
Screw 1/4-20 x 3/4 socket cap hex head stainless steel |
$0.99
|
1 |
|
usually ships 11-24 days |
6 |
999-0060
|
Washer 1/4 split lock plain finish |
$0.99
|
1 |
|
ships same day |
7 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
$0.99
|
1 |
|
ships same day |
8a |
246-0144
|
Belt guide pulley with bolt and nut |
Call for price
|
1 |
(includes 1b (1pc), 8b) |
usually ships 1-5 days |
8b |
999-0208
|
Bolt 7/16-20 x 1 1/2 hex head grade 5 zinc plated |
$0.99
|
1 |
|
ships same day |
