| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
241-5159
|
Recovery tank |
1 |
|
|
9 |
999-6684
|
Washer 1/4 flat stainless steel |
6 |
|
|
13 |
241-4094
|
Adapter |
1 |
|
|
14a |
241-4096
|
Cap |
1 |
|
|
14b |
241-4095
|
Gasket |
1 |
|
|
39 |
241-5166
|
Base skirt |
1 |
|
|
81 |
241-5082
|
Pump out filter |
1 |
|
|
91 |
241-5208
|
Bulkhead fitting |
1 |
|
|
92 |
241-5209
|
Nipple |
1 |
|
|
95 |
241-5214
|
Pump-out pump |
1 |
|
|
96 |
241-5215
|
90 degree elbow barb |
2 |
|
|
97 |
999-0570
|
Screw 10-24 x 1 1/4 pan head phillips stainless steel |
2 |
|
|
99 |
241-5216
|
Nylon barb |
1 |
|
|
105 |
241-5217
|
Barb |
1 |
|
|
