| # | Part | Description |
Req | Notes | Availability |
|---|
9 |
999-6684
|
Washer 1/4 flat stainless steel |
6 |
|
|
32 |
241-5012
|
12 inch wheel with hub |
2 |
|
|
37 |
241-5173
|
Base plate assembly |
1 |
(comes with lift handle and hinges) |
|
38 |
241-5174
|
Handle |
1 |
|
|
39 |
241-5166
|
Base skirt |
1 |
|
|
40 |
241-5175
|
Hinge |
3 |
|
|
41a |
999-1099
|
Bolt 1/4-20 x 3/4 hex head stainless steel |
6 |
|
|
41b |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
6 |
|
|
55 |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
6 |
|
|
56 |
999-1206
|
Screw 8-32 x 1/2 socket head stainless steel |
6 |
|
|
