| # | Part | Description |
Req | Notes | Availability |
|---|
8 |
241-4121
|
Screw 1/4-20 x 1/2mm |
4 |
|
|
9 |
999-6684
|
Washer 1/4 flat stainless steel |
4 |
|
|
15 |
241-5168
|
Barb |
1 |
|
|
16 |
992-3017
|
Rocker switch |
1 |
|
|
17 |
241-5228
|
2000 PSI pressure gauge |
1 |
|
|
18a |
241-5169
|
Knob |
1 |
|
|
18b |
241-4150
|
Unloader (OBSOLETE) |
1 |
|
|
19a |
241-5170
|
Screw 8-32 x 1 sohd stainless |
1 |
|
|
19b |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
1 |
|
|
20 |
241-5023
|
Circuit breaker |
1 |
|
|
21 |
241-5020
|
Female quick connect |
1 |
|
|
22 |
241-4086
|
Adapter |
1 |
|
|
23a |
999-0114
|
Washer 1/2 SAE flat |
1 |
|
|
23b |
999-1107
|
Washer 1/2 bonded neoprene stainless steel |
1 |
|
|
24 |
241-5171
|
Control panel plate |
1 |
|
|
25 |
241-5172
|
MX3-1200 panel decal |
1 |
|
|
100 |
241-5021
|
Male quick connect |
1 |
|
|
103 |
241-5167
|
Dual circuit light decal |
1 |
|
|
