| # | Part | Description | Price | Req | Notes | Availability |
|---|
EB1 |
240-1536
|
Disc control board panel |
$239.75
|
1 |
|
usually ships 16-41 days |
EB2 |
240-1537
|
Machine main controller |
$392.41
|
1 |
|
ships same day |
BAT |
N/A
|
Not available |
Call for price
|
4 |
(batteries) |
usually ships 3-26 days |
F1 |
240-1539
|
100amp fuse |
$22.80
|
1 |
|
usually ships 16-41 days |
F2 |
240-1618
|
40amp fuse |
$5.89
|
1 |
|
usually ships 16-41 days |
F3 |
240-1617
|
80amp fuse |
$17.68
|
1 |
|
usually ships 16-41 days |
CH1 |
240-1511
|
25amp onboard battery charger |
$945.16
|
1 |
|
usually ships 16-41 days |
K1 |
572-3666
|
SWITCH KEY WITH CAP PKD |
$74.79
|
1 |
|
usually ships 16-41 days |
K2 |
240-1533
|
Micro switch |
$4.78
|
1 |
|
usually ships 16-41 days |
SW |
240-6337
|
SWITCH |
$16.01
|
3 |
|
ships same day |
EV1 |
240-1565
|
24V solenoid valve |
$31.26
|
1 |
|
usually ships 16-41 days |
M1 |
240-1553
|
250W traction motor |
$767.91
|
1 |
|
usually ships 16-41 days |
M2a |
240-6634
|
24V 3 stage vacuum motor |
$165.72
|
1 |
|
usually ships 16-41 days |
M2b |
991-1230
|
24V 3 stage vacuum motor tangential with snout |
$168.80
|
1 |
(non-oem) |
ships same day |
M3 |
240-1569
|
Left hand brush motor kit |
$819.41
|
2 |
|
usually ships 16-41 days |
M4 |
240-1502
|
24V linear actuator |
$194.29
|
1 |
|
ships same day |
