| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
238-7032
|
Bail |
12.56 inch |
|
|
2a |
238-5397
|
Screw |
2 |
|
|
2b |
238-0198
|
Nut lock |
2 |
|
|
2c |
238-0199
|
Washer socket |
2 |
|
|
2d |
238-0200
|
Gasket |
2 |
|
|
3 |
238-0201
|
Nylon retainer (OBSOLETE) |
2 |
|
|
4 |
238-7033
|
Recover tank assembly with bail (OBSOLETE) |
1 |
|
|
5 |
238-7034
|
Wide track decal (OBSOLETE) |
1 |
|
|
6 |
238-5401
|
Decal |
1 |
|
|
10a |
238-5402
|
Dome skirtless (clear) |
1 |
|
|
10b |
238-5043
|
Dome kit |
1 |
|
|
11 |
238-5403
|
Dome gasket |
1 |
|
|
14 |
238-5131
|
90 degree dome elbow (black) |
2 |
|
|
16 |
238-5078
|
Washer (black) (OBSOLETE) |
2 |
|
|
17 |
238-5037
|
20-1/2 inch hose |
1 |
|
|
18 |
238-5404
|
Decal |
1 |
|
|
19 |
238-5036
|
14 inch hose |
1 |
|
|
20a |
238-5042
|
Dome filter with spring |
1 |
|
|
20b |
238-5405
|
Spring |
1 |
|
|
22 |
238-5077
|
Gasket |
2 |
|
|
23 |
238-5317
|
Retainer clip |
2 |
|
|
N/S |
238-5035
|
Upholstery tool with hose assembly |
1 |
|
|
