| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
238-5009
|
Pump kit - includes elbows and diodes |
|
|
|
3 |
238-5109
|
Cam assembly |
|
|
|
4 |
238-5092
|
Hose clamp |
|
|
|
5 |
238-5434
|
Bottom pan (black) (OBSOLETE) |
|
|
|
6 |
238-5444
|
Drive arm |
|
|
|
7 |
238-5099
|
Pillow block |
|
|
|
8 |
238-5029
|
Replacement brush - Mighty Pro |
|
|
|
9 |
238-5176
|
Screw (OBSOLETE) |
|
|
|
10 |
238-5103
|
Rubber pump mount |
|
|
|
12 |
238-5089
|
Cable tie (black) |
|
|
|
13 |
238-5003
|
Spray jet |
|
|
|
14 |
238-5436
|
Solution hose |
|
|
|
15 |
238-5087
|
C clip |
|
|
|
17 |
238-5052
|
Brush holder assembly |
|
|
|
18 |
238-5437
|
Screw |
|
|
|
19 |
238-5304
|
Nut |
|
|
|
20 |
238-5106
|
Sleeve |
|
|
|
21 |
238-5091
|
Bearing |
|
|
|
22 |
238-5097
|
Felt washer (OBSOLETE) |
|
|
|
23 |
238-5105
|
Bushing |
|
|
|
24 |
238-5101
|
Connector |
|
|
|
25 |
238-5005
|
Hose |
|
|
|
27 |
238-5025
|
Brush drive motor kit |
|
|
|
29 |
238-5006
|
90 degree barbed fitting |
|
|
|
30 |
238-5098
|
Screw |
|
|
|
31 |
238-5096
|
Screw |
|
|
|
32 |
238-5110
|
Washer (OBSOLETE) |
|
|
|
33 |
238-5093
|
Nut |
|
|
|
38 |
238-5440
|
Gasket seal |
|
|
|
39 |
238-5102
|
Motor gasket |
|
|
|
40 |
238-5441
|
Solution hose |
|
|
|
41 |
238-5442
|
Solution hose (OBSOLETE) |
|
|
|
46 |
238-5095
|
Rivet |
|
|
|
48 |
238-5443
|
Gasket |
|
|
|
49 |
238-5094
|
Washer |
|
|
|
51 |
238-5090
|
Washer (OBSOLETE) |
|
|
|
