| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
238-5359
|
Handle (OBSOLETE) |
|
|
|
2 |
238-5466
|
Push button switch |
|
|
|
3 |
238-5360
|
3 inch wire (white) |
|
|
|
4 |
238-5361
|
Access panel |
|
|
|
5 |
238-5362
|
Screw |
|
|
|
6 |
238-5247
|
Adjustment lever |
|
|
|
7 |
238-5333
|
1/2 inch spacer (OBSOLETE) |
|
|
|
9 |
238-5363
|
Decal |
|
|
|
10 |
238-5021
|
18/3 power cord 36 inch (black) |
|
|
|
11 |
238-5301
|
Bolt (OBSOLETE) |
|
|
|
12 |
238-5045
|
Threaded rod (OBSOLETE) |
|
|
|
13 |
238-5249
|
Threaded plunger (OBSOLETE) |
|
|
|
14 |
238-5334
|
Screw 8-32 x 1 1/2 binding post (OBSOLETE) |
|
|
|
20 |
238-5364
|
Bushing |
|
|
|
21 |
238-5248
|
Plunger spring (OBSOLETE) |
|
|
|
27 |
238-5302
|
Nut (OBSOLETE) |
|
|
|
38 |
238-5250
|
Nut |
|
|
|
39 |
238-5365
|
Sleeve |
|
|
|
40 |
238-5366
|
Decal |
|
|
|
41 |
238-5367
|
Decal |
|
|
|
42 |
238-5368
|
Closed end insulation connector |
|
|
|
43 |
238-5369
|
Female terminal |
|
|
|
44 |
238-5370
|
Clamp |
|
|
|
45 |
238-5039
|
Pop rivet |
|
|
|
46 |
238-5093
|
Nut |
|
|
|
