SOLARIS S514 Bottom Casing Assembly

#PartDescriptionPriceReqNotesAvailability
10 228-9200 Bottom casing Call for price 1 (includes 20-60) usually ships 17-33 days
20 228-9201 Shaft slide skid Call for price 3 usually ships 17-33 days
30 228-9202 Screw 4.0 x 14 raised head Call for price 7 usually ships 17-33 days
40 228-9203 Slide skid assembly Call for price 3 (includes 50-60) usually ships 17-33 days
50 N/A Not available Call for price 1 (pin) usually ships 3-26 days
60 N/A Not available Call for price 1 (spacer) usually ships 3-26 days
70 228-9204 Handle grip Call for price 1 usually ships 17-33 days
80a 228-9205 Suspension Call for price 1 usually ships 17-33 days
80b 228-9206 Suspension telescopic pipe Call for price 1 usually ships 17-33 days
90 228-9207 Buffer Call for price 1 usually ships 17-33 days
100 228-9208 Torsion spring Call for price 1 usually ships 17-33 days
110 228-9209 Vacuum cleaner bag bracket Call for price 1 usually ships 17-33 days
123 228-9210 Vacuum cleaner bag (OBSOLETE) Call for price 1 usually ships 17-33 days
125 228-9211 Cloth filter bag (OBSOLETE) Call for price 1 (includes 126) usually ships 17-33 days
126 228-9212 Lock Call for price 1 usually ships 17-33 days
130 228-9213 Dust compartment filter (3 pieces) Call for price 1 usually ships 17-33 days
140 228-9214 Filter frame Call for price 1 usually ships 17-33 days
150 228-9215 Seal Call for price 1 usually ships 17-33 days
160 228-9216 Sealing ring Call for price 1 usually ships 17-33 days
170 228-9217 Hose Call for price 1 usually ships 17-33 days
