| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
273-0081
|
Wirebound hose 1/2 x 21 inch |
1 |
|
|
2 |
227-1309
|
Hose (red) (OBSOLETE) |
1 |
|
|
3 |
227-1310
|
1/4 inch NPT check valve |
1 |
|
|
4 |
173-0684
|
Bushing |
1 |
|
|
5 |
173-1821
|
Hose clamp |
2 |
|
|
6 |
173-2098
|
Street elbow 1/4 |
1 |
|
|
7 |
173-6069
|
Wire bound hose |
1 |
|
|
8 |
173-2113
|
Hosebarb |
1 |
|
|
9 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
4 |
|
|
10 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
1 |
|
|
11 |
173-9763
|
Screw 10-32 x 1 1/4 |
4 |
|
|
12 |
173-3112
|
P clamp |
1 |
|
|
13 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
1 |
|
|
14 |
999-0998
|
Washer #10 flat stainless steel |
8 |
|
|
15 |
273-7186
|
150PSI pump assembly |
1 |
|
|
