| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
225-2071
|
Switch panel assembly w/ 2 switch, 2 breaker, hour meter |
$302.93
|
1 |
|
ships same day |
2 |
225-0145
|
Screw 3/4 inch stainless steel |
$0.99
|
4 |
|
usually ships 12-18 days |
3 |
225-2097
|
Pump assembly (KV17501QCBATT) |
$649.33
|
1 |
|
ships same day |
4 |
225-1128
|
Splash plate |
$56.72
|
1 |
|
usually ships 12-18 days |
5 |
225-0157
|
Nut 1/2 push cap |
$1.64
|
2 |
|
ships same day |
6 |
225-0379
|
8 inch wheel |
$71.53
|
2 |
|
ships same day |
7 |
225-0330
|
Thumb screw |
$4.83
|
2 |
|
ships same day |
8 |
225-0670
|
HEPA housing assembly |
$78.96
|
1 |
|
usually ships 12-18 days |
9 |
225-0381
|
Axle strap |
$20.93
|
2 |
|
usually ships 12-18 days |
10 |
999-0032
|
Washer 3/8 USS flat plain finish |
$2.42
|
2 |
|
ships same day |
11 |
225-0235
|
Cotter pin |
$0.99
|
8 |
|
ships same day |
12 |
999-0114
|
Washer 1/2 SAE flat |
$0.99
|
2 |
|
ships same day |
13 |
225-0378
|
Axle 20 1/2 x 1/2 inch |
$53.21
|
1 |
|
ships same day |
14 |
225-0688
|
36V vacuum motor assembly |
$508.16
|
1 |
|
ships same day |
15 |
225-0148
|
Nuts |
$0.99
|
1 |
|
usually ships 12-18 days |
16 |
999-0998
|
Washer #10 flat stainless steel |
$0.99
|
2 |
|
ships same day |
17 |
225-1130
|
Screw 10-24 x 1 flat head stainless steel |
$0.99
|
1 |
|
usually ships 12-18 days |
18 |
225-1131
|
Screw #10 18-8 stainless steel |
$0.99
|
1 |
|
usually ships 12-18 days |
19 |
225-1132
|
1/8 inch rivet stainless steel |
$0.99
|
2 |
|
usually ships 12-18 days |
20 |
225-1066
|
Nut |
$0.99
|
1 |
|
ships same day |
21 |
225-1133
|
Screw #6-32 x 3/8 |
$0.99
|
1 |
|
usually ships 12-18 days |
22 |
225-1134
|
NTC power pack bracket |
$95.68
|
1 |
|
ships same day |
23 |
225-0012
|
Screw #8 self drilling |
$0.99
|
2 |
|
ships same day |
KIT1 |
225-2098
|
Blackbox replacement assembly w/o inline filter |
$2,101.57
|
1 |
(includes 1-23) |
ships same day |
