Brush and Wheel Assembly

#PartDescription ReqNotesAvailability
1 220-1457 640 mm straight pipe 1
2 220-1458 Vacuum head 1
3 220-0697 Rivet 1
4 220-1459 Vacuum head locking tie 1
5 220-1460 Screw 8 x 16 8.8 1
6 220-0855 Lower part for handle 1
7 220-0622 Screw 2
8 220-4048 Metal washer 2
9 220-1461 Special screw 8 x 20 2
10 220-1462 Rod 1
11 220-0594 Locking nut 8
12 220-1463 Wheel shaft 1
13 220-1464 Wheel 60D 2
15 220-0530 Nut 3
17 220-1465 Lower rod 1
18 220-1466 Screw m8 x 65 2
19 220-1467 Upper rod 1
21 220-1468 Nut special 8D 1
22 220-1469 Spring 1
23 999-1309 Screw M6-1 x 30mm hex head zinc 1
24 220-0521 Washer 2
25 220-1470 Support bracket for brush housing 1
26 220-1471 Support bracket tie 1
27 220-0570 Screw 4
28 220-0770 Nut with washer 3
29 220-0790 Screw 3
30 220-0783 Washer 4
31 220-1472 Thimble 2
32 220-1473 Washer 2
33 220-1474 20D Wheel shaft 1
34 220-1475 Washer 20 x 28 x 0 1
35 220-0807 Seeger 1
36 220-1476 Locking plate 1
37 220-0522 Nut 2
39 220-4238 Pillow block 2
40 220-4230 Distance plate 4
41 220-0593 Washer 2
42 220-1477 Screw M8 x 30 zinc 2
43 220-0413 Wheel 2
46 220-1478 Brush housing fork 1
52 220-1479 Squeegee raising arm 1
53 220-0795 Vacuum head support 1
54 220-0802 Complete pawl 1
55 220-0796 Spring 1
56 220-0564 Washer 1
57 220-0533 Cotter pin 1
58a 220-1480 240V brush motor 1
58b 220-1481 120V brush motor 1
59 220-1482 Brush housing 1
60 220-1483 Motor pulley 1
61 220-0541 Stop dowel 1
62 220-0776 Screw 2
63 220-0815 Belt stretcher shaft 1
64 220-1484 Bearing stainless steel 1
65 220-0660 O-ring 1
66 220-0613 Lock washer 1
68 220-1485 Brush shaft 1
69 220-1486 Brush pulley 1
70 220-0542 Washer 1
72 220-0446 Seegar 1
73 220-0303 Bearing with support 2
74 220-1487 Special screw m6 x 14 1
75 220-1488 Brush belt 1
76 220-0444 Mialar disc 1
77 220-0443 Rubber gasket 1
78 220-1489 Brush 1
80 220-0618 Plate 2
82 220-0617 Pulley 1
83 220-0543 Screw 1
84 220-0621 Brass nut 1
85 220-0620 Locking nut 1
86 220-1490 Belt 1
87 220-0488 Screw 1
88 220-1492 3mm gasket 1
89 220-1491 Manifold clip 1
90 220-1448 Screw 4 x 8 1
91 220-1493 Motor cover 1
92 220-4009 Screw 1
93 220-1494 Motor cover plate 1
94 220-1495 Cover plate gasket 1
95 220-0425 Strain relief with nut 1
96 220-1496 Front nozzle 1
97 220-1497 Coupling 1
98 220-4047 Female quick disconnect 1
99 220-1498 Manifold assembly 1 (includes 100-107)
100 220-1499 Manifold 1
101 220-0555 Cap 1
102 220-0449 Manifold 5
103 220-0616 Quick disconnect support 5
104 220-0326 O-ring 5
105 220-0820 Green tip nozzle 5
106 220-0327 Nut 5
107 220-1500 Automatic coupling 1
108 220-0432 Quick disconnect 1
109 220-1501 Elbow 1
110 220-0897 Spring 1
111 220-1502 49 cm rilsan hose 1
112 220-1503 106cm rilsan hose 1
113 220-1504 Automatic coupling r23-8 1
114 220-0594 Locking nut 1
115 220-1505 5cm rilsan hose 2
116 220-0862 Coupling 2
117 220-1506 O ring 2
118 220-0577 Brass coupling 2
119 220-0576 Rubber pin 2
120 220-0575 Spring 2
121 220-1507 Coupling without spring 2
122 220-1508 37cm rilsan hose 1
123 220-1509 25cm rilsan hose 1
124 220-0668 Clip 1
