TT4550 Squeegee Assembly

#PartDescriptionPriceReqNotesAvailability
1a 220-4087 Top moulding $206.39 (TT3450) usually ships 16-24 days
1b 220-0354 Top molding $206.39 (TT4550) ships same day
2a 220-4088 Bottom moulding $206.39 (TT3450) (TT usually ships 16-24 days
2b 220-4089 Bottom moulding $206.39 (TT4550) usually ships 16-24 days
3 999-0870 Screw 8 x 3/4 pan head phillips stainless steel $0.99 ships same day
4 220-0251 Center moulding plus inserts $218.31 usually ships 16-24 days
5 220-4090 Washer $3.36 usually ships 16-24 days
6 220-4091 Knob assembly $27.17 usually ships 16-24 days
7 220-0331 T-knob $27.17 usually ships 16-24 days
8 220-0220 3 inch wheel $39.85 usually ships 16-24 days
9 193-0264 Washer M5-G stainless steel $4.49 usually ships 16-24 days
10 220-4086 Dome nut $2.31 usually ships 16-24 days
11 220-0297 Retaining pin $25.31 usually ships 16-24 days
12 220-0090 Screw insulator $4.31 usually ships 1-5 days
13 220-0268 2 inch wheel $8.64 usually ships 16-24 days
14 220-4092 Wheel insert $17.12 usually ships 16-24 days
15 220-4093 Height adjustment bracket $59.85 usually ships 16-24 days
16 220-4099 Bolt M6 x 35 $3.07 usually ships 16-24 days
17 220-4095 Bar $20.55 usually ships 16-24 days
18 220-4097 Starlock washer and cap $1.89 usually ships 16-24 days
19 193-0225 Washer M6-B $3.07 usually ships 1-5 days
20 193-0139 Nut M6 nylon insert stainless steel $5.50 ships same day
21 220-0087 Compression spring $6.81 usually ships 1-5 days
22 220-0086 Height adjustment shaft $39.67 usually ships 1-5 days
23 220-0089 Adjustment knob $60.57 usually ships 1-5 days
24 220-4096 Weight $59.82 usually ships 16-24 days
25 220-4098 Screw M5 x 30mm $4.37 usually ships 16-24 days
26a 193-0002 Squeegee blade rubber $75.30 (TT3450) usually ships 16-24 days
26b 220-0081 Squeegee blades 33 inch (sold individually) $47.04 (TT4550) usually ships 16-24 days
27a 193-0124 Squeegee blade rear polyurethane $81.90 (TT3450) usually ships 16-24 days
27b 220-0126 Squeegee blade rear $92.96 (TT4550) ships same day
28a N/A Not available Call for price (TT3450) usually ships 3-26 days
28b N/A Not available Call for price (TT4550) usually ships 3-26 days
