| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
220-0173
|
Handle |
|
|
|
2 |
220-0174
|
Handle casting |
|
|
|
3 |
220-0175
|
Adjustment gear |
|
|
|
4 |
220-0176
|
O ring |
|
|
|
5 |
220-0177
|
Gear locking pin |
|
|
|
6 |
220-0178
|
Spring |
|
|
|
7 |
220-0179
|
Handle locking rod |
|
|
|
8 |
193-0223
|
Half nut M6 |
|
|
|
9 |
220-0180
|
Plug |
|
|
|
10 |
220-4099
|
Bolt M6 x 35 |
|
|
|
11 |
999-1147
|
Bolt M6-1 x 40mm hex head stainless steel |
|
|
|
12 |
220-0181
|
Bracket |
|
|
|
13 |
220-4162
|
Screw |
|
|
|
14 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
|
|
|
15 |
220-0164
|
Washer |
|
|
|
16 |
220-4163
|
Bolt M8 x 25mm |
|
|
|
17 |
220-0182
|
Tube |
|
|
|
18 |
220-0183
|
Front inner molding |
|
|
|
19 |
220-0184
|
Rear inner molding |
|
|
|
20 |
220-0185
|
Handle relay mounting bracket |
|
|
|
21 |
220-0186
|
Front cover |
|
|
|
22 |
N/A
|
Not available |
|
|
|
23 |
220-0188
|
120V neon indicator |
|
|
|
24 |
220-0189
|
P-clip |
|
|
|
25 |
220-0190
|
Left hand switch lever |
|
|
|
26 |
220-0191
|
Right hand switch lever |
|
|
|
27 |
220-0192
|
Center switch lever |
|
|
|
28 |
220-0124
|
Hand grip molding |
|
|
|
29 |
193-0217
|
Trigger moulding |
|
|
|
30 |
220-0193
|
Adjustment lever |
|
|
|
31 |
193-0219
|
Washer M6 nylon |
|
|
|
32 |
220-0170
|
Nylon nut |
|
|
|
33 |
220-0194
|
Rear cover |
|
|
|
34 |
220-0195
|
Plug |
|
|
|
35 |
220-0196
|
Interlock lever |
|
|
|
36 |
220-0197
|
Handle plug |
|
|
|
37 |
220-0198
|
Terminal block |
|
|
|
38 |
220-0199
|
Terminal block cover |
|
|
|
39 |
220-0200
|
Contact pin |
|
|
|
40 |
220-0201
|
Earth contact pin |
|
|
|
41 |
220-4126
|
Screw M4 x 8mm |
|
|
|
42 |
220-0202
|
Socket cover |
|
|
|
43 |
220-0203
|
Cable clamp (black) |
|
|
|
44 |
220-0204
|
Plug |
|
|
|
45 |
220-0205
|
Tube end stop (black) |
|
|
|
46 |
220-0206
|
Cable clamp |
|
|
|
47 |
220-0207
|
25amp relay |
|
|
|
48 |
220-0208
|
Snap switch |
|
|
|
49 |
220-0209
|
4mm spirefix |
|
|
|
50 |
193-0028
|
Plastic screw |
|
|
|
51 |
220-4164
|
Screw M4 |
|
|
|
52 |
220-4165
|
Dome nut |
|
|
|
53 |
193-0225
|
Washer M6-B |
|
|
|
54 |
220-0210
|
Trigger compression spring |
|
|
|
55 |
220-0211
|
Switch compression spring |
|
|
|
57 |
193-0220
|
Screw 8 x 1 inch pan head self tap |
|
|
|
58 |
220-0109
|
Screw |
|
|
|
59 |
220-0212
|
Stress relief |
|
|
|
60 |
220-0213
|
Stress relief bracket |
|
|
|
61 |
220-4166
|
Shakeproof washer |
|
|
|
62 |
N/A
|
Not available |
|
(Screw) |
|
63 |
193-0221
|
Washer M4-A |
|
|
|
64 |
193-0218
|
Screw 8 x 1/2 inch pan head self tap |
|
|
|
65 |
999-0870
|
Screw 8 x 3/4 pan head phillips stainless steel |
|
|
|
66 |
220-4157
|
Washer |
|
|
|
67 |
220-0214
|
Switch |
|
|
|
68 |
220-0215
|
14/3 power cord (yellow) |
|
|
|
69 |
220-0216
|
Vacuum motor lead assembly |
|
|
|
70 |
220-0217
|
Solenoid valve lead assembly |
|
|
|
71 |
220-0218
|
Motor lead assembly |
|
|
|
72 |
220-4167
|
Washer M10 |
|
|
|
N/S |
220-0404
|
Illuminated rocker switch (green) |
|
|
|
