| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-1353
|
Nut 10-32 hex nylon lock insert stainless steel |
4 |
|
|
2 |
206-1203
|
Locknut |
1 |
|
|
3 |
206-1204
|
Screw 10-32 x 1 phillips stainless steel (OBSOLETE) |
4 |
|
|
4 |
206-4820
|
Washer |
4 |
|
|
5 |
206-5431
|
Clamp |
1 |
|
|
6 |
206-1192
|
Pipe fitting |
1 |
|
|
7 |
206-1193
|
Elbow fitting |
1 |
|
|
8 |
206-1194
|
Elbow |
1 |
|
|
9 |
206-1195
|
Pipe fitting |
1 |
|
|
10 |
206-1196
|
Hose adapter |
1 |
|
|
11 |
217-0029
|
Dump valve |
1 |
|
|
13 |
206-1198
|
Standpipe (OBSOLETE) |
1 |
|
|
14 |
206-1199
|
Cord wrap |
1 |
|
|
15 |
206-1189
|
Recovery tank (black) |
1 |
|
|
16 |
206-1200
|
PVC pipe |
1 |
|
|
17 |
206-1201
|
Support |
1 |
|
|
18 |
206-1202
|
Standpipe assembly |
1 |
|
|
