| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
N/A
|
Not available |
1 |
(Handle) |
usually ships 3-26 days |
2 |
216-0047
|
Power cord 50 ft 14/3 |
1 |
|
usually ships 1-5 days |
3 |
N/A
|
Not available |
1 |
(Control panel) |
usually ships 3-26 days |
4 |
N/A
|
Not available |
1 |
(Circuit breaker) |
usually ships 3-26 days |
5 |
216-0034
|
Rocker switch 115V |
1 |
|
usually ships 12-14 days |
6 |
216-0048
|
Master switch |
1 |
|
usually ships 1-5 days |
7 |
N/A
|
Not available |
1 |
(Wiring harness) |
usually ships 3-26 days |
8 |
N/A
|
Not available |
1 |
(Strain relief) |
usually ships 3-26 days |
9 |
216-0344
|
Bolt |
1 |
|
usually ships 12-14 days |
10 |
N/A
|
Not available |
1 |
(Screw) |
usually ships 3-26 days |
11 |
N/A
|
Not available |
4 |
(Washer) |
usually ships 3-26 days |
12 |
N/A
|
Not available |
4 |
(Washer) |
usually ships 3-26 days |
13 |
216-0088
|
Screw #6 x 3/4mm pan head stainless steel |
6 |
|
usually ships 1-5 days |
14 |
N/A
|
Not available |
1 |
(Gasket) |
usually ships 3-26 days |
15 |
216-0017
|
Heavy duty relay |
1 |
|
usually ships 12-14 days |
16 |
N/A
|
Not available |
1 |
(Terminal board) |
usually ships 3-26 days |
17 |
N/A
|
Not available |
1 |
(Circuit breaker) |
usually ships 3-26 days |
18 |
N/A
|
Not available |
1 |
(Filter) |
usually ships 3-26 days |
19 |
190-0848
|
Screw |
2 |
|
usually ships 12-14 days |
20 |
N/A
|
Not available |
2 |
(Screw) |
usually ships 3-26 days |
21 |
216-0165
|
Nut 10-32 kep zinc |
2 |
|
usually ships 12-14 days |
22 |
N/A
|
Not available |
1 |
(Plate) |
usually ships 3-26 days |
23 |
N/A
|
Not available |
1 |
(Cable tie) |
usually ships 3-26 days |
24 |
999-0916
|
Screw 8-32 x 1/2 pan head phillips stainless steel |
2 |
|
usually ships 11-14 days |
25 |
N/A
|
Not available |
2 |
(Screw) |
usually ships 3-26 days |
26 |
N/A
|
Not available |
4 |
(Nut) |
usually ships 3-26 days |
27 |
N/A
|
Not available |
1 |
(Washer) |
usually ships 3-26 days |
28 |
N/A
|
Not available |
1 |
(Nut) |
usually ships 3-26 days |
