2012 Tank Assembly - External

#PartDescriptionPriceReqNotesAvailability
1 174-8632 15 gallon tank stainless steel $421.53 1 usually ships 1-5 days
2 174-8616 Tank handle $82.80 2 usually ships 1-5 days
3 174-8617 Handle clamp $23.17 2 usually ships 1-5 days
4 174-8634 Adapter $539.46 1 usually ships 1-5 days
5 174-8618 PVC tip $1.66 2 usually ships 1-5 days
6 174-8635 Handle assembly $82.67 1 usually ships 1-5 days
7 999-0442 Nut 10-24 nylon insert lock stainless steel $1.76 4 ships same day
8 174-2401 Latch $16.33 2 usually ships 12-16 days
9 999-0998 Washer #10 flat stainless steel $0.99 4 ships same day
10 174-8625 Nut 8-32 hex head stainless steel $1.08 1 usually ships 1-5 days
11 174-5406 Washer 8 helical $1.08 1 usually ships 12-16 days
12 999-0266 Washer #8 SAE flat stainless steel $0.99 1 ships same day
13 174-2253 Intake deflector $19.20 1 usually ships 1-5 days
14 174-0049 Nut 1 1/2 pipe thread $2.22 1 usually ships 12-16 days
15 174-6143 Screw 8 - 32 x 1/2 $1.08 1 usually ships 1-5 days
16 174-5159 Washer 33/64 x 1/64 wave $1.10 2 usually ships 12-16 days
17 174-2262 Diecut poron intake gasket $1.22 1 usually ships 12-16 days
18 999-0855 Washer 9/16 SAE flat $0.99 2 ships same day
19 174-0178 1/2 inch external retaining ring $1.10 2 usually ships 12-16 days
20 174-0057 Gate valve $62.58 1 usually ships 12-16 days
21 174-1458 Rubber washer $1.17 4 usually ships 1-5 days
22 174-2259 3 inch caster wheel (gray) $20.26 2 usually ships 12-16 days
23 174-0822 Screw 1/4-20 x 1/3 $1.08 4 usually ships 12-16 days
24 999-0081 Screw 1/4-20 x 5/8 pan head slotted zinc $0.99 6 ships same day
25 174-8636 Wheel bracket Call for price 1 usually ships 1-5 days
26 174-8627 Screw M10-24 x 3/4 Call for price 4 usually ships 1-5 days
27 174-8537 Intake assembly (OBSOLETE) Call for price 1 usually ships 1-5 days
28 175-1594 Drain valve $59.51 3 usually ships 1-5 days
29 174-3149 Hub cap $1.48 2 usually ships 12-16 days
30 999-0016 Washer 1/4 flat plain finish $0.99 4 ships same day
31 999-0018 Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated $0.99 4 ships same day
32 174-8538 Mounting bracket weldment $106.13 1 usually ships 1-5 days
33 174-8539 Plastic tool holder basket $28.00 1 usually ships 1-5 days
34 174-8510 8 inch wheel $33.21 2 usually ships 12-16 days
35 174-0827 Plated axle $4.87 2 usually ships 12-16 days
36 174-5718 Bolt 1/4 20 x 5/8 hex head $1.08 4 usually ships 1-5 days
37 N/A Not available Call for price 1 (Water valve assembly) usually ships 3-26 days
38 174-8620 Bag ring gasket $42.71 1 usually ships 1-5 days
39 174-8492 Bag retaining ring $57.96 1 usually ships 12-16 days
40 174-1930 Hollow rubber ball $64.84 1 usually ships 1-5 days
41 174-1931 Cage float assembly $74.67 1 usually ships 12-16 days
42 174-0536 Washer 1/4 $1.08 4 usually ships 12-16 days
43 999-0190 Nut 1/4-20 hex plain finish $0.99 4 ships same day
44 174-8465 Filter bag $32.80 1 usually ships 12-16 days
45 174-2895 Bag spring retainer $12.57 1 usually ships 12-16 days
46 174-8540 Decal Call for price 1 usually ships 1-5 days
