| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
210-5593
|
Chassis assembly |
1 |
|
|
2 |
210-5594
|
Motor assembly with 1 inch shaft |
1 |
|
|
3 |
210-1001
|
Warning plate |
1 |
|
|
4 |
210-1000
|
Rivet |
4 |
|
|
6 |
210-1117
|
Screw 38-16 x 5 |
1 |
|
|
7 |
210-5595
|
Bearing retainer |
1 |
|
|
8 |
999-0120
|
Washer 3/8 SAE flat |
1 |
|
|
9 |
210-1112
|
Knob |
1 |
|
|
10 |
210-1111
|
Nut |
1 |
|
|
11 |
210-0988
|
Tube socket |
1 |
|
|
13 |
210-5601
|
Chassis handle |
2 |
|
|
14a |
210-5602
|
SP15 chassis |
1 |
|
|
15a |
210-1163
|
Bumper |
1 |
|
|
15b |
210-5603
|
Bumper |
1 |
|
|
16 |
210-0994
|
Bracket |
1 |
|
|
17 |
210-0993
|
Spacer |
2 |
|
|
18 |
210-1114
|
Polisher wheel |
2 |
|
|
19 |
210-5604
|
Wheel shaft |
2 |
|
|
110 |
210-0995
|
Flat washer |
1 |
|
|
112 |
210-1120
|
Washer stainless steel |
4 |
|
|
113 |
210-0070
|
Washer .850 x .017 end play |
6 |
|
|
114 |
210-5606
|
Yoke shaft |
6 |
|
|
116 |
210-5607
|
Chassis cap |
4 |
|
|
117 |
210-5608
|
Dust control nozzle |
2 |
|
|
