| # | Part | Description |
Req | Notes | Availability |
|---|
046 |
208-0090
|
Plug |
2 |
|
|
052 |
N/A
|
Not available |
1 |
Seat available in kit 208-0096 |
|
053 |
N/A
|
Not available |
1 |
Screw available in kit 208-0096 |
|
054 |
N/A
|
Not available |
1 |
Spherical valve available in kit 208-0096 |
|
056 |
N/A
|
Not available |
1 |
Anti-ext ring available in kit 208-0096 |
|
057 |
N/A
|
Not available |
1 |
O-ring available in kit 208-0096 |
|
058 |
N/A
|
Not available |
1 |
Guide available in kit 208-0096 |
|
059 |
N/A
|
Not available |
1 |
Anti-ext ring available in kit 208-0096 |
|
060 |
208-0095
|
Spring plate |
1 |
|
|
061 |
N/A
|
Not available |
1 |
Piston available in kit 208-0096 |
|
062 |
N/A
|
Not available |
2 |
O-ring available in kit 208-0096 |
|
063 |
N/A
|
Not available |
2 |
Anti-ext ring available in kit 208-0096 |
|
064 |
N/A
|
Not available |
1 |
Ball available in kit 208-0096 |
|
065 |
N/A
|
Not available |
3 |
O-ring available in kit 208-0096 |
|
066 |
N/A
|
Not available |
1 |
Spring available in kit 208-0096 |
|
067 |
N/A
|
Not available |
1 |
Stem available in kit 208-0096 |
|
068 |
N/A
|
Not available |
1 |
O-ring available in kit 208-0096 |
|
069 |
N/A
|
Not available |
1 |
Guide available in kit 208-0096 |
|
070 |
208-0098
|
Spring |
1 |
|
|
071 |
208-0099
|
Regulator knob |
1 |
|
|
072 |
208-0100
|
O-ring |
1 |
|
|
073 |
208-0101
|
Screw M8 set |
1 |
|
|
074 |
208-0102
|
Nut M8 |
1 |
|
|
075 |
208-0103
|
Lock nut |
1 |
|
|
076 |
208-0104
|
Lock sleeve |
1 |
|
|
077 |
208-0105
|
Handle |
1 |
|
|
090 |
208-0106
|
Injector banjo bolt |
1 |
|
|
091 |
N/A
|
Not available |
1 |
O-ring available in kit 208-0107 |
|
092a |
208-0108
|
Injector |
1 |
|
|
092b |
208-0109
|
Fixed injector |
1 |
|
|
093 |
N/A
|
Not available |
1 |
O-ring available in kit 208-0107 |
|
094 |
N/A
|
Not available |
1 |
Ball available in kit 208-0107 |
|
095 |
N/A
|
Not available |
1 |
Conical spring available in kit 208-0107 |
|
096 |
N/A
|
Not available |
1 |
O-ring available in kit 208-0107 |
|
097 |
N/A
|
Not available |
1 |
Spring available in kit 208-0107 |
|
098 |
208-0110
|
O-ring |
1 |
|
|
099 |
208-0111
|
Shutter |
1 |
|
|
100 |
208-0112
|
Knob |
1 |
|
|
101 |
208-0113
|
O-ring |
2 |
Available in kit 208-0107 |
|
102 |
208-0114
|
Hose barb |
1 |
|
|
120 |
208-0115
|
M22 nipple |
1 |
|
|
121a |
208-0116
|
2mm Nozzle |
1 |
|
|
121b |
208-0117
|
2.2mm Nozzle |
1 |
|
|
122 |
208-0118
|
O-ring |
1 |
|
|
123 |
208-0119
|
O-ring |
1 |
Available in kit 208-0107 |
|
124 |
208-0120
|
M14-1.5 Injector plug |
1 |
Available in kit 208-0107 |
|
