| # | Part | Description |
Req | Notes | Availability |
|---|
2 |
206-1175
|
Pacific Floorcare decal |
1 |
|
|
3 |
206-1176
|
Serial number decal |
1 |
|
|
4 |
206-1177
|
Warning decal |
1 |
|
|
5 |
206-1178
|
Bottom exhaust cover |
1 |
|
|
6 |
206-1179
|
Exhaust filter (OBSOLETE) |
1 |
|
|
7 |
206-1180
|
Knob (OBSOLETE) |
2 |
|
|
8 |
206-1181
|
Foam support plate |
1 |
|
|
9 |
206-1182
|
Spacer |
1 |
|
|
10 |
206-1183
|
Spacer |
1 |
|
|
11 |
206-1142
|
Shoulder screw |
2 |
|
|
12 |
999-1544
|
Screw 8-32 x 1/2 truss head phillips stainless steel |
2 |
|
|
13 |
206-1184
|
Sound reduction foam |
1 |
|
|
