| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
206-1138
|
Brush height decal |
1 |
|
|
2 |
206-1139
|
Tapered pin |
1 |
|
|
3 |
206-1140
|
Front shaft weldment |
1 |
|
|
4 |
206-1141
|
Wheel |
2 |
|
|
5 |
999-0593
|
Nut 5/16-18 hex stainless steel |
2 |
|
|
6 |
999-1350
|
Screw 10-32 x 1/2 inch phillips pan head stainless steel |
1 |
|
|
7 |
206-1142
|
Shoulder screw |
2 |
|
|
8 |
999-0053
|
Washer #10 split lock plain finish |
1 |
|
|
