| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
206-3611
|
Foot pedal |
1 |
|
|
2 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
2 |
|
|
3 |
206-3617
|
Adjustment rod |
1 |
|
|
4 |
999-1544
|
Screw 8-32 x 1/2 truss head phillips stainless steel |
4 |
|
|
5 |
206-3618
|
Plate |
1 |
|
|
6 |
206-3619
|
Gasket |
1 |
|
|
7 |
206-3620
|
Cotter pin |
1 |
|
|
8 |
999-0794
|
Screw 8-32 x 5/16 pan head phillips stainless steel |
4 |
|
|
9 |
206-3621
|
Vacuum door plate |
1 |
|
|
10 |
206-3622
|
Door seal |
1 |
|
|
N/S |
206-3623
|
Seal |
1 |
|
|
