S-20 Scrub Deck Assembly

#PartDescriptionPriceReqNotesAvailability
1 206-3469 Brush gear motor $1,331.69 1 usually ships 13-21 days
2 206-4034 Carbon brush kit $157.92 1 usually ships 13-21 days
3 999-0414 Screw 10-32 x 3/4 pan head slotted zinc plated $0.99 1 ships same day
4 206-3118 Cable clamp $2.71 1 usually ships 1-5 days
5 999-1353 Nut 10-32 hex nylon lock insert stainless steel $0.99 1 ships same day
6 206-3471 Motor mounting plate $135.60 1 ships same day
7 206-4820 Washer $3.14 12 usually ships 13-21 days
8 999-0297 Bolt 1/4-20 x 1 hex head stainless steel $2.53 4 ships same day
9 206-3474 Spacer $8.46 1 usually ships 13-21 days
10 206-3470 Square keyway $3.86 1 usually ships 13-21 days
11 206-4035 Brush hub $204.31 1 ships same day
12 206-4037 Press-in plunger ball $48.73 1 ships same day
13 206-3316 Left hand driver guide $64.35 1 usually ships 13-21 days
14 999-1824 Screw 1/4-20 x 5/8 flat head socket stainless steel $2.01 3 ships same day
15 206-3344 Plastic pad guide $106.61 1 ships same day
16 999-0024 Washer 5/16 flat stainless steel $1.34 1 ships same day
17 999-0553 Washer 5/16 medium split lock stainless steel $0.99 1 ships same day
18 999-0501 Bolt M8-1.25 x 25mm hex head full thread stainless steel $2.64 1 ships same day
19 206-3473 Shroud $93.17 1 usually ships 1-5 days
20 206-3341 Skirt $121.82 1 usually ships 13-21 days
21 999-0395 Screw 1/4-20 x 5/8 button head socket plain finish $0.99 4 ships same day
22 999-0294 Nut 1/4-20 hex nylon lock type NE stainless steel $1.18 4 ships same day
23 206-1600 Guide wheel spacer $50.46 1 usually ships 13-21 days
24 206-3274 Guide wheel $5.86 1 usually ships 13-21 days
25 206-1599 Washer 1/2 inch nylon $2.95 1 usually ships 13-21 days
26 206-1598 Compression spring $11.00 1 usually ships 13-21 days
27 999-1825 Screw 5/16-18 x 1 1/2 flat head socket SS $2.00 1 ships same day
28 206-1602 Wheel replacement kit $28.07 1 (includes 23-27) usually ships 13-21 days
29 999-1689 Screw M6-1 x 30mm set stainless steel $3.70 4 (pad assist model) ships same day
30 999-0497 Nut M6-1 nylon insert lock stainless steel $0.99 4 (pad assist model) ships same day
31 206-4038 Washer $1.09 6 (pad assist model) usually ships 13-21 days
32 999-0152 Nut 1/4-20 nylon insert lock zinc plated $0.99 4 ships same day
33 206-3472 Support bracket $64.92 1 ships same day
34 999-0593 Nut 5/16-18 hex stainless steel $0.99 1 ships same day
35 206-5233 Washer 5/16 x .040 flat $2.59 3 ships same day
36 206-3319 Plastic roller $11.17 1 usually ships 13-21 days
37 206-3315 Spacer $16.35 1 usually ships 13-21 days
39 999-0551 Bolt 5/16-18 x 1 3/4 hex head stainless steel $1.63 1 ships same day
40 206-3773 Pad driver $295.00 1 usually ships 13-21 days
41a 206-3770 19 inch polypropylene brush $338.20 1 usually ships 13-21 days
41b 206-3771 19 inch nylon brush $542.84 1 usually ships 13-21 days
41c 206-3772 19 inch grit brush $901.60 1 usually ships 1-5 days
N/S 999-0060 Washer 1/4 split lock plain finish $0.99 4 ships same day
N/S 999-1383 Screw M6-1 x 16mm hex head stainless steel $3.96 4 (traction drive model) ships same day
N/S 206-1388 Pad holder $66.18 usually ships 13-21 days
N/S 206-3774 Clutch plate $54.29 usually ships 13-21 days
KIT1 206-4036 Shroud assembly $241.62 1 (includes 7, 19-22) usually ships 13-21 days
