| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
206-3231
|
Reducer fitting |
1 |
|
|
2 |
206-0157
|
Clear hose (sold by the inch) |
1 |
|
|
3 |
206-0080
|
Hose clamp |
6 |
|
|
4 |
206-1515
|
24V solution pump |
1 |
|
|
5 |
206-3192
|
Screen filter |
1 |
|
|
6 |
999-1532
|
Screw 1/4-20 x 1/2 hex head stainless steel |
2 |
|
|
7 |
206-1516
|
Valve mounting bracket |
1 |
|
|
8 |
999-0060
|
Washer 1/4 split lock plain finish |
4 |
|
|
9 |
206-4025
|
24V solenoid valve |
1 |
|
|
10 |
206-3228
|
Cap |
1 |
(only used on models with chemical injection) |
|
11 |
999-1099
|
Bolt 1/4-20 x 3/4 hex head stainless steel |
2 |
(only used on models with chemical injection) |
|
12 |
206-3227
|
Mounting bracket |
1 |
(only used on models with chemical injection) |
|
13 |
206-3232
|
3/16 inch tubing (sold by the inch) |
1 |
(only used on models with chemical injection) |
|
14 |
206-3235
|
Hose clamp |
3 |
(only used on models with chemical injection) |
|
15 |
206-3229
|
Check valve |
1 |
(only used on models with chemical injection) |
|
16 |
206-3230
|
Tee fitting |
1 |
(only used on models with chemical injection) |
|
17 |
206-3225
|
24V solenoid pump |
1 |
(only used on models with chemical injection) |
|
18 |
206-3226
|
Heat sink bracket |
1 |
(only used on models with chemical injection) |
|
19 |
999-1350
|
Screw 10-32 x 1/2 inch phillips pan head stainless steel |
2 |
(only used on models with chemical injection) |
|
20 |
206-0134
|
Suction strainer |
1 |
(only used on models with chemical injection) |
|
21 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
(only used on models with chemical injection) |
|
