| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
203-5975
|
On/off switch |
1 |
|
|
2 |
203-5976
|
Connect bracket |
1 |
|
|
3 |
189-2243
|
5-10 inch M. 3 screw |
10 |
|
|
4 |
203-5977
|
Rear cover |
1 |
|
|
5 |
203-5878
|
Screw 4x16 |
9 |
|
|
6 |
203-5978
|
36V wiring |
1 |
|
|
7 |
203-5979
|
Washer 5 x 20 inox |
4 |
|
|
8 |
203-4956
|
Spring lock washer |
4 |
|
|
9 |
203-5980
|
Screw 5x20 |
2 |
|
|
10 |
203-5981
|
Wheel |
2 |
|
|
11 |
375-9483
|
Screw M5 x 16 inox |
2 |
|
|
12 |
203-1286
|
Washer D6 |
4 |
|
|
13 |
203-5982
|
Front squeegee bracket |
2 |
|
|
14 |
203-5983
|
Shaft |
2 |
|
|
15 |
375-5391
|
Washer 12D |
5 |
|
|
16 |
203-5984
|
Spacer |
4 |
|
|
17 |
203-5985
|
Rear squeegee support |
2 |
|
|
18 |
203-5986
|
Frame |
1 |
|
|
19 |
203-5987
|
Solution tank filter |
1 |
|
|
20 |
203-5988
|
Right hand floor wiper spring |
1 |
|
|
21 |
203-5989
|
Lever |
1 |
|
|
22 |
203-5990
|
Left hand floor wiper spring |
1 |
|
|
23 |
203-5991
|
Covering brush |
1 |
|
|
24 |
203-5992
|
Plate |
2 |
|
|
25 |
203-5993
|
Screw 3 1/2 x 16 |
4 |
|
|
26 |
203-5994
|
Front squeegee wheel |
1 |
|
|
27 |
203-5995
|
Cover |
1 |
|
|
28 |
203-5996
|
Insulator |
1 |
|
|
29 |
203-5997
|
Right hand lever |
1 |
|
|
30 |
203-5998
|
Washer D.12 x 36 inox |
2 |
|
|
31 |
203-5999
|
Pin |
2 |
|
|
32 |
203-6000
|
Shaft |
2 |
|
|
33a |
203-9104
|
Arm |
1 |
|
|
33b |
162-0114
|
12V 50Ah AGM battery |
1 |
|
|
34 |
203-6002
|
Isolator |
1 |
|
|
35 |
203-6003
|
Left hand lever |
1 |
|
|
36 |
203-6004
|
Spring |
2 |
|
|
37 |
203-6005
|
On/off spring |
1 |
|
|
38 |
203-6006
|
Screw 3 1/2 x 32 |
1 |
|
|
N/S |
375-9493
|
Battery charger |
1 |
|
|
