Reliable 18E
Wiring Diagram
Click to enlarge
#
Part
Description
Price
Req
Notes
Availability
EV1
N/A
Not available
Call for price
1
(Solenoid valve)
usually ships 3-26 days
F1
203-4960
16amp fuse
$9.36
1
usually ships 5-15 days
F2
203-4961
5amp fuse (OBSOLETE)
$12.52
1
usually ships 5-15 days
M1
203-5004
115V motor
$479.06
1
usually ships 5-15 days
M2
203-5000
Bracket
$1,193.68
1
usually ships 5-15 days
