CT90 Crankcase Assembly

#PartDescriptionPriceReqNotesAvailability
1 203-3629 Decal $5.21 1 usually ships 10-12 days
2 203-3630 Front panel $83.69 1 usually ships 10-12 days
4 203-3631 Decal Call for price 2 usually ships 10-12 days
5 203-3632 Recovery tank $893.71 1 usually ships 10-12 days
6 203-3633 Solution tank $893.71 1 usually ships 10-12 days
7 203-5643 Decal $10.15 1 usually ships 10-12 days
8 203-5615 Decal $5.30 1 usually ships 10-12 days
10 203-3634 Front panel $275.26 1 usually ships 10-12 days
11 203-3635 Screw 5 x 10 thread cutting $2.40 4 usually ships 10-12 days
12 203-5648 Adhesive $6.37 2 usually ships 10-12 days
13 203-5642 Adhesive $5.30 2 usually ships 10-12 days
14 203-5644 Adhesive $6.37 1 usually ships 10-12 days
15 203-3636 Bracket $39.86 2 usually ships 10-12 days
16 203-4713 Screw $4.25 4 usually ships 1-5 days
20 996-1204 Nylon brush $170.50 2 usually ships 1-5 days
24 N/A Not available Call for price 1 (instruction manual) usually ships 3-26 days
25 N/A Not available Call for price 1 (manual) usually ships 3-26 days
26 N/A Not available Call for price 1 (plastic envelope) usually ships 3-26 days
27 203-5651 Tube $8.34 1 usually ships 10-12 days
28 203-4166 50amp charger plug (red) $62.58 1 usually ships 10-12 days
29 N/A Not available Call for price 1 (envelope) usually ships 3-26 days
