Gansow CT46 Squeegee Assembly

#PartDescriptionPriceReqNotesAvailability
1 203-5534 Sheet metal $16.01 1 usually ships 10-12 days
2 203-5537 Sheet metal $16.01 1 usually ships 10-12 days
3 203-5541 Right hand rear squeegee retainer $24.01 1 usually ships 10-12 days
4 203-5543 Left hand rear squeegee retainer $23.82 1 usually ships 10-12 days
5 203-5546 Support $45.85 1 usually ships 10-12 days
6 203-5545 Support $16.85 1 usually ships 10-12 days
7 203-5538 Squeegee body $55.55 1 usually ships 10-12 days
8 203-5426 Insert $24.26 2 usually ships 10-12 days
9 189-5086 Bushing $15.42 2 usually ships 10-12 days
10 203-4765 Retainer closure $10.41 2 usually ships 10-12 days
11 203-4780 Closure $0.99 2 usually ships 10-12 days
12 203-0524 Nut M6 lock $5.50 2 usually ships 1-5 days
13 189-1536 Nut with nylon ring $5.50 4 usually ships 5-9 days
14 203-4787 Nut M3 $3.61 8 usually ships 10-12 days
15 203-5430 Spacer $9.41 2 usually ships 10-12 days
16 203-0920 Spacer $11.00 2 usually ships 10-12 days
17 203-5421 Decal $28.06 2 usually ships 10-12 days
18 189-0181 Gasket $2.97 2 usually ships 10-12 days
19 203-5535 Squeegee blade rubber front $55.26 1 ships same day
20 203-5539 Squeegee blade rubber rear $55.36 1 ships same day
21 203-4768 Knob $10.01 2 ships same day
22 203-4772 Socket $7.60 2 usually ships 10-12 days
23 189-1393 Washer $2.99 8 usually ships 1-5 days
24 203-1286 Washer D6 $2.99 2 usually ships 10-12 days
25 189-1391 Washer D6 $0.99 2 usually ships 10-12 days
26 189-1398 Washer 6 x 24 inch $2.99 2 usually ships 10-12 days
27 203-5429 Wheel $2.97 2 usually ships 10-12 days
28 675-9813 Wheel 80D x 22W bumper $24.31 2 usually ships 10-16 days
29 189-1488 Screw M6 $4.20 2 usually ships 10-12 days
30 189-1539 Screw $4.20 2 usually ships 10-12 days
31 203-4788 Screw 3 x 8 inch $4.20 8 usually ships 10-12 days
32 203-5428 Screw M6 $4.20 2 usually ships 10-12 days
