PERFORMER28 Electrical Schematic

#PartDescriptionPriceReqNotesAvailability
AP1 203-2870 Traction card $976.79 usually ships 1-5 days
AP2 189-2248 Board $149.97 usually ships 1-5 days
FU1 203-1703 Fuse $34.88 usually ships 1-5 days
FU4 203-3133 30amp fuse $2.13 usually ships 1-5 days
FU5 203-3346 10amp fuse $5.22 usually ships 1-5 days
FV1 203-1850 Diode (OBSOLETE) Call for price usually ships 1-5 days
FV2 203-1850 Diode (OBSOLETE) Call for price usually ships 1-5 days
H 203-1054 Hour meter (OBSOLETE) Call for price usually ships 1-5 days
HL1 189-0832 Circuit board $87.11 usually ships 5-15 days
KM1 203-4144 Connection (contactor) $377.23 usually ships 1-5 days
KM3 189-0105 Relay $178.90 usually ships 5-15 days
M1 203-1755 Gear motor $1,116.34 usually ships 1-5 days
M2 203-1755 Gear motor $1,116.34 usually ships 1-5 days
M3 203-0804 Motor $653.63 usually ships 1-5 days
M4 189-2222 Transaxle $1,632.63 usually ships 1-5 days
M5 203-1751 Actuator $627.94 usually ships 5-15 days
QM1 N/A Not available Call for price (not available) Thermal protection usually ships 3-26 days
QM2 N/A Not available Call for price (not available) Thermal protection usually ships 3-26 days
QM3 N/A Not available Call for price (not available) Thermal protection usually ships 3-26 days
R1 203-1708 Resistance $59.60 usually ships 1-5 days
R2 189-0450 Resistance $62.72 usually ships 1-5 days
RP1 189-0259 Potentiometer $122.87 usually ships 5-15 days
S1 203-1851 Microswitch (OBSOLETE) Call for price usually ships 1-5 days
S2 189-0258 Microswitch $17.22 usually ships 5-15 days
S3 189-0258 Microswitch $17.22 usually ships 5-15 days
S4 189-0258 Microswitch $17.22 usually ships 5-15 days
S5 203-1754 Microswitch $62.79 usually ships 5-15 days
S6 203-1852 Microswitch (OBSOLETE) Call for price usually ships 1-5 days
S7 203-1852 Microswitch (OBSOLETE) Call for price usually ships 1-5 days
S8 203-1754 Microswitch $62.79 usually ships 5-15 days
SB2 189-2223 Switch $53.53 usually ships 5-15 days
SB3 203-3345 Push button $15.30 usually ships 1-5 days
VD1 203-1853 Diode $44.48 usually ships 1-5 days
VD2 189-0455 Bridge / Jumper $48.75 usually ships 1-5 days
VD3 203-1853 Diode $44.48 usually ships 1-5 days
XC1 203-0882 Support (OBSOLETE) $21.49 usually ships 1-5 days
XC2 203-0882 Support (OBSOLETE) $21.49 usually ships 1-5 days
XC3 203-0882 Support (OBSOLETE) $21.49 usually ships 1-5 days
XC4 203-0947 Clamp $1.87 usually ships 1-5 days
XP1 203-4166 50amp charger plug (red) $51.36 usually ships 5-15 days
