| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-0515
|
Solution flow control knob |
1 |
|
|
2 |
202-9899
|
PVC cable guide |
1 |
|
|
3 |
202-9982
|
Handle bar |
1 |
|
|
4 |
202-9896
|
Lever |
1 |
|
|
5 |
202-9983
|
Lever bracket |
1 |
|
|
6 |
202-9845
|
23-1/4 squeegee lift cable (black) |
1 |
|
|
7 |
202-5307
|
Handlebar mounting bracket |
4 |
|
|
8 |
202-0869
|
Switch cover |
2 |
|
|
9 |
202-0879
|
Push button switch |
2 |
|
|
10 |
202-2254
|
Heat shrink |
4 |
|
|
11 |
999-0190
|
Nut 1/4-20 hex plain finish |
2 |
|
|
12 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
1 |
|
|
13 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
1 |
|
|
14 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
8 |
|
|
15 |
999-0150
|
Washer #8 medium split lock |
4 |
|
|
16 |
999-0916
|
Screw 8-32 x 1/2 pan head phillips stainless steel |
4 |
|
|
17 |
999-9136
|
Screw 1/4-20 x 2 3/4 pan head phillips stainless steel |
8 |
|
|
18 |
999-9241
|
Washer 1 1/2 x 25/64 x 39/64 flat nylon |
2 |
|
|
19 |
999-9242
|
Screw 1/4-20 x 1 1/4 button head socket cap |
1 |
|
|
20 |
999-1507
|
Screw 5/16-18 x 1 button head socket stainless steel |
1 |
|
|
21 |
999-9243
|
Screw 5/16-18 x 1 flat head socket cap (3/16 hex drive) |
1 |
|
|
