| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-9975
|
Solution fill curtain |
1 |
|
|
2 |
202-9869
|
Solution fill screen |
1 |
|
|
3 |
202-9871
|
Vacuum motor insulation |
1 |
|
|
4 |
202-9976
|
Decal |
2 |
|
|
5 |
202-9977
|
Brand decal |
2 |
|
|
6 |
202-9978
|
Brand decal |
1 |
|
|
7 |
202-9979
|
Bulldog solution tank |
1 |
|
|
8 |
202-9876
|
Strainer screen (blue) |
1 |
|
|
9 |
202-1487
|
Latch |
1 |
|
|
10 |
202-4200
|
Fill hose |
1 |
|
|
11 |
202-5648
|
4 inch hinge stainless steel |
2 |
|
|
12 |
999-1049
|
Washer 1/4 split lock zinc plated |
4 |
|
|
13 |
999-0019
|
Bolt 1/4-20 x 5/8 hex head grade 5 zinc plated |
4 |
|
|
14 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
15 |
999-0358
|
Screw 8-32 x 5/8 pan head phillips stainless steel |
2 |
|
|
16 |
202-3440
|
Barbed elbow |
1 |
|
|
17 |
202-9877
|
Elbow |
1 |
|
|
18 |
202-4225
|
Hose |
1 |
|
|
